G0513 Series Bandsaws
-95-
G0513X2F Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 PSS01M SET SCREW M6-1 X 10 59 PCAP06M CAP SCREW M6-1 X 25
3 P0513X003 BUSHING 60 P0513060 STAR KNOB
4 P0513004 LIFTING EYE BOLT M10-1.5 61 PLN03M LOCK NUT M6-1
5 P0513X2F005 MACHINE BODY 62 P0513062 STRAIN RELIEF 16MM STRAIGHT LT
7 P0513X007 BUSHING 63 P0513063 HEIGHT POINTER
8 PW03M FLAT WASHER 6MM 64 PN03M HEX NUT M8-1.25
10 PN01M HEX NUT M6-1 65 PB124M HEX BOLT M8-1.25 X 90
11 P0513011 POINTER 66 P0513066 STAR KNOB BOLT M10-1.5 X 20
12 P0513012 STEP SCREW M4-.7 X 5 67 P0513067 STAR KNOB BOLT M10-1.5 X 55
13 P0513013 HINGE SHAFT 68 P0513068 THREADED HANDLE M10-1.5
14 PRP10M ROLL PIN 5 X 36 69 P0513069 CAM
15 P0513015 UPPER WHEEL SHAFT HINGE 70 P0513070 PILLOW BLOCK
16 P0513016 UPPER WHEEL SHAFT 71 P0513071 HANDLE M12-1.75
17 P0513X2B017 UPPER WHEEL ASSEMBLY 72 P0513072 LEVER
17-1 P0513017 BUSHING 73 PN09M HEX NUT M12-1.75
17-2 P6204-2RS BALL BEARING 6204-2RS 74 P0513074 LEVER HUB
17-3 PR25M INT RETAINING RING 47MM 75 PBHS01M BUTTON HD CAP SCR M8-125 X 20
17-4 P0513X019 UPPER WHEEL 17" 76 PLW04M LOCK WASHER 8MM
17-5 T23071 URETHANE TIRE 17" 1-PAIR 78 P0513078 SHAFT COVER
18 P0513X2B018 LOWER WHEEL ASSEMBLY 79 PSS09M SET SCREW M8-1.25 X 20
18-1 P0513017 BUSHING 80 PN03M HEX NUT M8-1.25
18-2 P6204-2RS BALL BEARING 6204-2RS 81 P0513X2F081 LOWER WHEEL SHAFT
18-3 PR25M INT RETAINING RING 47MM 82 P0513082V2 MOTOR 2HP 110V/220V 1-PH
18-4 P0513X027 LOWER WHEEL 17" 82-1 P0513082-1V2 MOTOR FAN COVER
18-5 T23071 URETHANE TIRE, 1-PAIR 82-2 P0513082-2V2 MOTOR FAN
21 P0513X021 WHEEL FLAT WASHER 8MM 82-3 P0513082-4V2 CAPACITOR COVER
22 PCAP11M CAP SCREW M8-1.25 X 16 82-4 PC040G R CAPACITOR 40M 250V 1-3/8 X 2-5/8
23 P0513023 SAW BLADE 131.5" X 1/2" 6TPI HOOK 82-5 P0513082-7V2 MOTOR JUNCTION BOX
24 PLW04M LOCK WASHER 8MM 82-6 PC300T S CAPACITOR 300M 250V 1-1/2 X 2-3/8
25 PCAP14M CAP SCREW M8-1.25 X 20 82-7 PCP001 CONTACT PLATE 5/8
28 P0513X2F028 WHEEL PULLEY/BRAKE DRUM 82-8A P0513082-9A CENTRIFUGAL SWITH W/CONT PLATE
29 PN32 HEX NUT 1-14 82-8 PCS001 CENTRIFUGAL SWITCH 5/8-1725
30 PLW09 LOCK WASHER 1" 82-9 P6205ZZ BALL BEARING 6205ZZ
32 P0513032 COMPRESSION SPRING 7 X 8 X 90 82-10 P6203ZZ BALL BEARING 6203ZZ
33 PRP02M ROLL PIN 3 X 16 83 PB32M HEX BOLT M10-1.5 X 25
34 P0513034 ALIGNMENT PLATE 84 PLW06M LOCK WASHER 10MM
35 P51201 THRUST BEARING 51201 85 P0513085 MOTOR MOUNT BRACKET
37 P0513037 TENSION HANDWHEEL 86 PBHS01M BUTTON HD CAP SCR M8-125 X 20
38 P0513038 TENSION ADJUSTING ROD 87 P0513X2B087 STRAIN RELIEF PLATE 1-HOLE
39 PFS07M FLANGE SCREW M5-.8 X 10 88 PFS07M FLANGE SCREW M5-.8 X 10
43 P0513X2B031 CONTROL PANEL PLATE 89 P0513089 PILLOW BLOCK
44 PCAP11M CAP SCREW M8-1.25 X 16 90 PK15M KEY 5 X 5 X 35
45 PWF08M FENDER WASHER 8MM 91 PB81M HEX BOLT M8-1.25 X 20 LH
46 P0513046 UPPER WHEEL SLIDING BRACKET 92 P0513092 MOTOR PULLEY TYPE-A 3.5"
47 PCAP05M CAP SCREW M8-1.25 X 50 93 PVA42 V-BELT A42
48 PRIV005M STEEL BLIND RIVET 3 X 13MM 94 PCAP04M CAP SCREW M6-1 X 10
49 PCAP04M CAP SCREW M6-1 X 10 95 P0513095 LOWER WHEEL COVER
50 P0513050 CLEAR WINDOW 97 PWF08M FENDER WASHER 8MM
55A P0513X2055A UPPER WHEEL COVER ASSY 111 PCAP02M CAP SCREW M6-1 X 20
55 P0513055 UPPER WHEEL COVER 119 PW05M FLAT WASHER 4MM
56 PB10M HEX BOLT M6-1 X 25 188 PFS07M FLANGE SCREW M5-.8 X 10
57 PW03M FLAT WASHER 6MM 189 P0513X2F189 CORD CLIP 5/16"
58 P0513058 WHEEL BRUSH 190 PHTEK15M TAP SCREW M4 X 10
To Next Page
