Page #98 background image
-96-
G0513 Series Bandsaws
G0513X2F Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
193 P0513X2F193 KEY SWITCH 242-2 P0513X2F242-2 OL RELAY SDE RA-20 8-12A
194 P0513X2B041 START BUTTON 242-3 P0513X2F242-3 MAG SWITCH COVER ASSEMBLY
195 P0513X2B040 STOP BUTTON 242-4 P0513X2F242-4 CONTROL CORD 16G 3W
196 PFS09M FLANGE SCREW M5-.8 X 50 242-5 P0513031 MOTOR CORD 14G 3W
197 P0513X2F197 JUNCTION BOX 243 PS09M PHLP HD SCR M5-.8 X 10
198 PWRN01 WIRE NUT 14-22G 244 P0513X2F244 MAG SWITCH ASSY 110V MPE-18
199 PTLW02M EXT TOOTH WASHER 5MM 244-1 P0513X2F244-1 CONTACTOR SDE MA-18 110V
200 PS38M PHLP HD SCR M4-.7 X 10 244-2 P0513X2F244-2 OL RELAY SDE RA-30 18-26A
242 P0513X2F242 MAG SWITCH ASSY 220V MPE-09 244-3 P0513X2F244-3 MAG SWITCH COVER ASSEMBLY
242-1 P0513X2F242-1 CONTACTOR SDE MA-09 220-240V
