Model G0602/G0752 (Mfd. Since 03/17)
-73-
Figure 114. Right motor junction box.Figure 113. Left motor junction box.
G0752 Motor Wiring Diagram
Motor 1HP 220V 3PH
Motor Fan
110V 30W 1PH
Ground
Neutral
Hot
Ground
110 VAC
5-15 Plug
(As Recommended)
U1
W1
N1
L1
PE
L
N
V1
PE
To Wiring
Box
Page 69
To Wiring
Box
Page 69
To Wiring
Box
Page 69
