Model G0755 (Mfg. Since 1/13)
-29-
order online at www.grizzly.com or call 1-800-523-4777
G976020-PC. 2 & 4 Flute TiN End Mill Set.
Includes these sizes and styles in two and four
flute styles:
3
/16",
1
/4",
5
/16",
3
/8",
7
/16",
1
/2",
9
/16",
5
/8",
3
/8",
11
/16", and
3
/4".
Figure 36. G9760 20-PC End Mill Set.
G5774R-8 End Mill Holder Set
Hold various sized end mills in your R-8 spindle
with this End Mill Holder Set. Includes holders for
3
16",
3
8",
1
2",
5
8" and
3
4" end mills.
Figure 37. G5774 R-8 End Mill Holder Set.
G9612—Test Indicator
This Test Indicator has a 0.03" range in gradu-
ations of 0.0005", an easy-to-read dial, and a
pivoting stylus that moves at right angles to the
dial face.
Figure 38. G9612 Test Indicator.
Figure 41. G3658 Titanium Drill Bits.
G5641—1-2-3 Blocks
G9815Parallel Set
Blocks are square to within .0003". Measure 1" x
2" x 3". Parallel set measures 6" long by
1
2",
5
8",
3
4",
7
8", 1",
11
8",
11
4",
11
8",
13
8",
11
2", and
15
8".
Figure 39. G5641 1-2-3 Blocks and G9815
Parallel Set.
H59304-Pc Center Drill Set 60°
H59314-Pc Center Drill Set 82°
Double ended HSS Center Drills are precision
ground. Includes sizes 1-4.
Figure 40. H5930 4-pc Center Drill Set 60°.
G3658Titanium Drill Bits
Titanium nitride-coated bits last up to six times as
long as uncoated bits. This 115-piece set features
29 fractional bits, from
1
6" to
1
2" in increments
of
1
64", letter bits from A–Z, and 60 number bits.
Housed in rugged steel case.
