Grizzly G0755 User Manual

-50-
Model G0755 (Mfg. Since 1/13)
Table & Column Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P0755201 BASE 258 PR24M INT RETAINING RING 42MM
202 P0755202 COLUMN 259 P0755259 FLANGED BEARING CAP
203 P0754203 Y-AXIS LEADSCREW BRACKET 260 P0755260 Z-AXIS LEADSCREW
204 P0755204 HEAD MOUNT 261 P51104 THRUST BEARING 51104
205 P0755205 Z-AXIS GIB 262 PK07M KEY 6 X 6 X 20
206 P0754206 GIB ADJUSTMENT SCREW 263 P0755263 SPANNER NUT LOCK WASHER 20MM
207 P51103 THRUST BEARING 51103 264 P0755264 SPANNER NUT M20-1.5
208 P0755208 Y-AXIS LEADSCREW 265 PCAP06M CAP SCREW M6-1 X 25
209 P0754209 DIAL CLUTCH 266 P0755266 DOWEL PIN 6 X 30
210 P0754210 TABLE GRADUATED DIAL 267 P0755267 Z-AXIS CRANK
211 P0754211 TABLE HANDWHEEL 268 P0755268 SHOULDER SCREW M10-1.5 X 20 90L
212 P0754094 HANDWHEEL HANDLE 269 P0755269 CRANK HANDLE
213 P0754213 SHOULDER SCREW M8-1.25 X 12 72L 280 PR15M EXT RETAINING RING 30MM
214 P0755214 Z-AXIS LEADSCREW NUT 281 P0755281 SPACER
215 P0755215 LEADSCREW NUT BRACKET 282 P0755282 LOWER COUPLER
218 PCAP14M CAP SCREW M8-1.25 X 20 283 P0755283 NYLON SHAFT
219 P0754219 DOWEL PIN 5 X 45 284 P0755282 UPPER COUPLER
220 P0754096 KNURLED THUMB SCREW M5-.8 X 12 285 P0755281 SPACER
221 PLUBE002M TAP-IN BALL OILER 8MM 286 PR15M EXT RETAINING RING 30MM
222 P0754222 ADJUSTABLE HANDLE M8-1.25 287 P0755287 STAND
223 PLW10M LOCK WASHER 16MM 288 P0755288 STAND SIDE COVER
224 PW08M FLAT WASHER 16MM 291 PW06M FLAT WASHER 12MM
225 PCAP123M CAP SCREW M16-2 X 60 292 P0755292 CAP SCREW M12-1.75 X 140
226 P0755226 HEAD MOUNT FLAT WASHER 12MM 313 P0755313 MOTOR MOUNT
227 PCAP111M CAP SCREW M12-1.75 X 35 314 PCAP31M CAP SCREW M8-1.25 X 25
228 P0755228 COLUMN REAR COVER 315 P0755315 ELEVATION MOTOR 1/8HP 220V 1-PH
230 PCAP26M CAP SCREW M6-1 X 12 315-1 P0755315-1 MOTOR FAN COVER
231 P0755231 DOWEL PIN 8 X 30 315-2 P0755315-2 MOTOR FAN
235 P0755235 SADDLE 315-3 P0755315-3 MOTOR JUNCTION BOX
236 P0755236 TABLE 315-4 P6001ZZ BALL BEARING 6001ZZ
237 P0754237 X-AXIS LEADSCREW NUT 315-5 P6000ZZ BALL BEARING 6000ZZ
238 P0754238 Y-AXIS LEADSCREW NUT 316 PCAP31M CAP SCREW M8-1.25 X 25
239 P0754239 X-AXIS LEADSCREW RIGHT BRACKET 317 P0755317 DOWEL PIN 5 X 25
240 P0755240 X-AXIS LEADSCREW LEFT BRACKET 318 PS09M PHLP HD SCR M5-.8 X 10
241 P0755241 X-AXIS LEADSCREW 319 P0755319 LIMIT SWITCH CHINT YBLX-JW2/11H/L
242 P0755242 POWER FEED CLUTCH 320 P0755320 Z-AXIS LIMIT BLOCK
244 PW01M FLAT WASHER 8MM 321 PCAP02M CAP SCREW M6-1 X 20
245 PCAP38M CAP SCREW M5-.8 X 25 322 P0755322 SPACER
246 PCAP45M CAP SCREW M8-1.25 X 45 323 PCAP201M CAP SCREW M8-1.25 X 6
248 P0755248 TABLE GIB 324 PW01M FLAT WASHER 8MM
249 PCAP38M CAP SCREW M5-.8 X 25 325 P0754274 POWER FEED LIMIT SWITCH
252 P0755252 SADDLE GIB 326 PR39M EXT RETAINING RING 8MM
254 P0755254 Z-AXIS GEAR HOUSING 327 P0754276 T-SLOT NUT M8-1.25
255 P0755255 Z-AXIS CRANK SHAFT 328 P0754277 POWER FEED LIMIT STOP
256 P0755256 GEAR 12T 329 P0754278 COMPRESSION SPRING
257 P0755257 BALL BEARING 604ZZ 330 P0754279 LIMIT STOP HOUSING
