Model G0704 (Mfd. Since 05/16)
-3-
Identification
Figure 1. G0704 Identification.
A. Drawbar Cap and Drawbar
B. Vertical (Z-Axis) Handwheel
C. Speed Range Selector Knob
D. Vertical Travel Lock
E. Fine Feed Lock Knob
F. Quill Feed Lever
G. Table
H. Longitudinal (X-Axis) Handwheel
I. Longitudinal Table Stop
J. Table Cross Travel Locks
K. Table Longitudinal Travel Lock
L. Table Center Stop
M. Machine Stand
N. Storage Access Door
O. Cross (Y-Axis) Handwheel
P. Longitudinal Scalev
Q.
Drill Chuck
R. Headstock Tilt Scale
S. Chip Guard
T. Quill Lock Lever
U. Fine Feed Knob
V. Digital Readout (Page 4)
W. Control Panel (Page 4)
X.
Headstock
Y. Column
