Grizzly G0759 User Manual

-48-
Model G0704 (Mfd. Since 05/16)
Column Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0704001 Z-AXIS SLIDE 41 P0704041 Z-AXIS HANDWHEEL HANDLE M6-1 X 10
2 P0704002 SET SCREW M6-1 X 16 42 P0704042 BALL BEARING 6001ZZ
3 P0704003 FLAT WASHER 8MM 43 P0704043 Z-AXIS HANDWHEEL SHAFT
4 P0704004 LOCK WASHER 8MM 44 P0704044 KEY 4 X 4 X 12
5 P0704005 CAP SCREW M8-1.25 X 25 45 P0704045 PILLOW BLOCK
6 P0704006 FLAT WASHER 12MM 46 P0704046 SPACER
7 P0704007 LOCK WASHER 12MM 47 P0704047 PINION GEAR
8 P0704008 CAP SCREW M12-1.75 X 40 48 P0704048 COLUMN
9 P0704009 T-BOLT M10-1.5 49 P0704049 Z-AXIS SCALE
10 P0704010 FLAT WASHER 10MM 50 P0704050 THREADED SLEEVE M6-1 X 16
11 P0704011 LOCK WASHER 10MM 51 P0704051 CAP SCREW M6-1 X 14
12 P0704012 HEX NUT M10-1.5 52 P0704052 X-AXIS LEADSCREW BRACKET (LH)
13 P0704013 SLIDE ALIGNMENT BLOCK 54 P0704054 TABLE
14 P0704014 BRASS PIN 55 P0704055 COOLANT HOSE FITTING
15 P0704015 ADJUSTABLE HANDLE M6-1 X 16 56 P0704056 X-AXIS LEADSCREW BRACKET (RH)
16 P0704016 GIB ADJUSTMENT SCREW 57 P0704057 TABLE HANDWHEEL HANDLE M6-1 X 10
17 P0704017 Z-AXIS GIB 58 P0704058 TABLE HANDWHEEL
18 P0704018 HEADSTOCK ANGLE SCALE 59 P0704059 TABLE GRADUATED DIAL
19 P0704019 CAP SCREW M5-.8 X 10 60 P0704060 THRUST BEARING 51200
20 P0704020 Z-AXIS WAY COVER 61 P0704061 CAP SCREW M6-1 X 10
21 P0704021 HEX NUT M5-.8 62 P0704062 LIMIT STOP
22 P0704022 Z-AXIS WAY COVER BRACKET 63 P0704063 T-NUT M6-1
23 P0704023 Y-AXIS WAY COVER 64 P0704064 X-AXIS SCALE
24 P0704024 Y-AXIS WAY COVER BRACKET 65 P0704065 X-AXIS LEADSCREW
25 P0704025 LEADSCREW LOCK NUT M16-1.5 66 P0704066 X-AXIS LEADSCREW NUT
26 P0704026 THRUST BEARING 51203 67 P0704067 CAP SCREW M4-.7 X 20
27 P0704027 RING GEAR 68 P0704068 SADDLE
28 P0704028 KEY 4 X 4 X 16 69 P0704069 TABLE STOP BLOCK
29 P0704029 Z-AXIS LEADSCREW 70 P0704070 Y-AXIS GIB
30 P0704030 Z-AXIS LEADSCREW NUT 71 P0704071 Y-AXIS LEADSCREW NUT
31 P0704031 CAP SCREW M5-.8 X 12 72 P0704072 X-AXIS GIB
31-1 P0704031-1 FLAT WASHER 5MM 73 P0704073 CAP SCREW M6-1 X 25
32 P0704032 BEARING COVER 74 P0704074 X-AXIS BEARING HOUSING
33 P0704033 CAP SCREW M8-1.25 X 20 75 P0704075 Y-AXIS LEADSCREW
34 P0704034 COLUMN TOP PLATE 76 P0704076 BASE
35 P0704035 COLLAR FLANGE 77 P0704077 CAP SCREW M12-1.75 X 90
36 P0704036 CAP SCREW M5-.8 X 12 100 P0704100 STAND ASSEMBLY
37 P0704037 Z-AXIS GRADUATED DIAL 100-1 P0704100-1 STAND CABINET
38 P0704038 Z-AXIS HANDWHEEL 100-2 P0704100-2 STAND DOOR
39 P0704039 HANDWHEEL CURVED PLATE SPRING 100-3 P0704100-3 STAND DOOR LATCH
40 P0704040 HEX NUT M8-1.25
