Grizzly G0759 User Manual

Model G0704 (Mfd. Since 05/16)
-51-
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P0704201 QUILL RETAINING CLIP 238-1 P0704238-1 ROUND INSPECTION COVER
202 P0704202 BUSHING 238-2 P0704238-2 CAP SCREW M4-.7 X 8
203 P0704203 COMPRESSION SPRING 239 P0704239 COVER PLATE
204 P0704204 EXT RETAINING RING 45MM 240 P0704240 CAP SCREW M4-.7 X 8
205 P0704205 BALL BEARING 6209ZZ 241 P0704241 FINE FEED KNOB
206 P0704206 COMBO GEAR 60/70T 242 P0704242 FRONT COVER
206-1 P0704206-1 SPINDLE RING 16MM 243 P0704243 HANDWHEEL CURVED PLATE SPRING
206-2 P0704206-2 CAP SCREW M3-.5 X 8 244 P0704244 FINE FEED COLLAR
207 P0704207 BALL BEARING 6007-2RS 245 P0704245 WORM SHAFT
208 P0704208 EXT RETAINING RING 15MM 246V2 P0704246 SPINDLE V2.08.11
209 P0704209 GEAR 37T 15MM ID BORE 246-1 P0704246-1 DRAWBAR
209-1 P0704209-1 GEAR GUARD 246-2 P0704246-2 RETAINER CUP
209-2 P0704209-2 CAP SCREW M3-.5 X 6 247 P0704247 SPINDLE RING
210 P0704210 EXT RETAINING RING 32MM 248 P0704248 TAPERED ROLLER BEARING 32005
211 P0704211 BALL BEARING 6002ZZ 249 P0704249 QUILL SLEEVE
212 P0704212 COMBO GEAR 42/62T 250 P0704250 RUBBER RING
213 P0704213 SHAFT 251 P0704251 ADJUSTER NUT
214 P0704214 KEY 5 X 5 X 50 252 P0704252 ADJUSTER NUT SCREW
215 P0704215 KEY 5 X 5 X 12 254 P0704254 PIN 6 X 30
216 P0704216 FORK 255 P0704255 HANDLE
217 P0704217 FORK ARM 255-1 P0704255-1 HANDLE GRIP
218 P0704218 SET SCREW M5-.8 X 8 256 P0704256 SELECTOR KNOB
219 P0704219 DRAWBAR CAP 257 P0704257 DOWNFEED HUB
220 P0704220 MOTOR COVER V1 258 P0704258 DOWNFEED COLLAR
221V3 P0704221V3 MOTOR 1HP 110V (14MM SHAFT) V3.04.13 259 P0704259 COMPRESSION SPRING
221-1V2 P0704221-1V2 CARBON BRUSH 1-PC V2.11.12 260 P0704260 CAP SCREW M4-.7 X 40
221-2V2 P0704221-2V2 CARBON BRUSH CAP 1-PC V2.11.12 261 P0704261 DOWNFEED FLANGE
222 P0704222 FLAT WASHER 4MM 262 P0704262 SPACER
223 P0704223 CAP SCREW M4-.7 X 8 263 P0704263 WORM GEAR
224 P0704224 CAP SCREW M6-1 X 14 264 P0704264 KEY 4 X 4 X 12
225 P0704225 SENSOR BRACKET 265 P0704265 GEAR SHAFT
225-1 P0704225-1 SENSOR CORD 266 P0704266 RIVET
225-2 P0704225-2 CAP SCREW M3-.5 X 6 267 P0704267 HIGH/LOW ARROW PLATE
226 P0704226 RPM SENSOR 268 P0704268 SET SCREW M8-1.25 X 8
227 P0704227 MOTOR PLATE 269 P0704269 COMPRESSION SPRING
228 P0704228 CAP SCREW M5-.8 X 12 270 P0704270 STEEL BALL 6.5MM
229V2 P0704229V2 EXT RETAINING RING 14MM 271 P0704271 SPEED SELECTOR KNOB
230V2 P0704230V2 GEAR 20T (ID 14MM) V2.04.13 272 P0704272 SET SCREW M5-.8 X 16
231V2 P0704231V2 KEY 5 X 5 X 15 273 P0704273 SPEED KNOB PLATE
232 P0704232 SET SCREW M5-.8 X 6 274 P0704274 FORK SHAFT FLANGE
233 P0704233 CAP SCREW M3-.5 X 6 275 P0704275 FORK SHAFT
234 P0704234 DIGITAL READOUT UNIT 276 P0704276 CAP SCREW M3-.5 X 6
234-1 P0704234-1 DIGITAL READOUT BRACKET 292 P0704292 SPINDLE PIN
234-2 P0704234-2 CAP SCREW M4-.7 X 10 293 P0704293 DRILL CHUCK ARBOR R8 X B16
235 P0704235 BASE BLOCK 294 P0704294 DRILL CHUCK B16 3-16MM
236 P0704236 QUILL LOCKING LEVER 295 P0704295 CHUCK KEY FOR B16 16MM CHUCK
237 P0704237 BRASS PIN 296 P0704296 TAPERED ROLLER BEARING 32007
238 P0704238 MILL HEAD CASTING
Headstock Parts List
