Model G0704 (Mfd. Since 05/16)
Inventory
Contents Qty
A. Mill/Drill w/Stand ......................................... 1
B.
Open End Combo Wrench 17/19 ................ 1
C.
Open End Combo Wrench 8/10 ................. 1
D.
Bottle for Oil ............................................... 1
E.
Tool Box...................................................... 1
F.
Large Handwheel Handle ........................... 1
G. Small Handwheel Handles ......................... 3
H.
T-Bolts M10-1.5 x 60 (vise mounting) ......... 2
Flat Washers 10mm (vise mounting) .......... 2
Hex Nuts M10-1.5 (vise mounting).............. 2
I.
Drill Chuck .................................................. 1
J.
Chuck Key .................................................. 1
K.
Phillips Screwdriver .................................... 1
L.
Flat Screwdriver .......................................... 1
M.
Arbor B16 x R8 ........................................... 1
N.
Hex Wrench Set 2, 3, 4, 5, & 6mm ...... 1 ea.
O. Spindle Pin ................................................. 1
Not Shown:
Hex Bolts M10-1.5 x 50 .............................. 4
Flat Washers 10mm ................................... 4
Figure 4. G0704 out of the crate.
A
Figure 5. Inventory.
B
D
E
GH
IJ
LK
M
C
F
N
O
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
