-44-
Model G0761 (Mfd. Since 10/13)
Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0761001 HEADSTOCK HOUSING 45 P0761045 GEAR 25T
2 P0761002 HEADSTOCK TOP COVER 46 P0761046 GEAR 18T
3 P0761003 INT RETAINING RING 62MM 47 P0761047 GEAR 32T
4 P0761004 INT RETAINING RING 35MM 48 P0761048 GEAR 43T
5 P0761005 FLANGED END CAP 49 P0761049 GEAR 16T
6 P0761006 SHAFT SEAL 45 X 35 X 10 50 P0761050 KEY 5 X 5 X 50
7 P0761007 MOTOR 2HP 220V 1-PH 51 P0761051 KEY 6 X 6 X 18
7-1 P0761007-1 MOTOR FAN COVER 52 P0761052 KEY 6 X 6 X 18
7-2 P0761007-2 MOTOR FAN 53 P0761053 QUILL
7-3 P0761007-3 MOTOR JUNCTION BOX 54 P0761054 SPINDLE R-8
7-4 P0761007-4 S CAPACITOR 150M 250V 1-5/8 X 3 55 P0761055 TAPERED ROLLER BEARING 30207 P5
7-5 P0761007-5 R CAPACITOR 20M 450V 1-1/2 X 3-1/4 56 P0761056 TAPERED ROLLER BEARING 30206 P5
7-6 P0761007-6 CENTRIFUGAL SWITCH 25MM 1725 RPM 57 P0761057 GEAR SHAFT 25T
7-7 P0761007-7 CONTACT PLATE 58 P0761058 GEAR 53T
7-8 P0761007-8 BALL BEARING 6205ZZ 59 P0761059 EXT RETAINING RING 35MM
7-9 P0761007-9 BALL BEARING 6205ZZ 60 P0761060 DEPTH ROD MOUNT
8 P0761008 HEX BOLT M8-1.25 X 25 61 P0761061 INT THREADED SHOULDER BOLT M16-2 X 10
9 P0761009 FLAT WASHER 8MM 62 P0761062 HEX NUT M16-2 THIN
10 P0761010 HEADSTOCK FRONT COVER 63 P0761063 DEPTH ROD KNURLED THUMB KNOB M16-2
11 P0761011 DRAWBAR CAP 64 P0761064 STUD-FT M12-1.75 X 230
12 P0761012 DRAWBAR CAP RUBBER SEAL 65 P0761065 DEPTH ROD DOG
13 P0761013 CAP SCREW M8-1.25 X 45 66 P0761066 DEPTH POINTER
14 P0761014 TAPER PIN 8 X 40 67 P0761067 SPANNER NUT LOCK WASHER 30MM
15 P0761015 CAP SCREW M10-1.5 X 8 68 P0761068 SPANNER NUT M30-1.5
16 P0761016 SET SCREW M10-1.5 X 10 DOG-PT 69 P0761069 RUBBER SEAL 90 X 75 X 6
17 P0761017 KEY 6 X 6 X 28 70 P0761070 CAP SCREW M4-.7 X 8
18 P0761018 OIL FILL PLUG 3/8" ZG 71 P0761071 ROLL PIN 3 X 18
19 P0761019 CASTING PLUG 72 P0761072 CAP SCREW M8-1.25 X 30
20 P0761020 SHIFT LEVER 73 P0761073 SPACER
21 P0761021 ROLL PIN 3 X 18 74 P0761074 SPINDLE END SEAL
22 P0761022 OIL DRAIN PLUG 3/8" ZG 75 P0761075 SET SCREW M5-.8 X 6 DOG-PT
23 P0761023 PHLP HD SCR M5-.8 X 10 76 P0761076 SET SCREW M5-.8 X 4
24 P0761024 BUTTON HD CAP SCR M4-.7 X 8 77 P0761077 WORM GEAR HOUSING
25 P0761025 OIL SIGHT GLASS M18-1.5 78 P0761078 WORM SHAFT
26 P0761026 DRIVE SHAFT 79 P0761079 WORM SHAFT END BRACKET
27 P0761027 GEAR 14T 80 P0761080 SET SCREW M6-1 X 12
28 P0761028 BALL BEARING 6003ZZ 81 P0761081 SPACER
29 P0761029 BALL BEARING 6007ZZ 82 P0761082 WORM GEAR
30 P0761030 KEY 5 X 5 X 25 83 P0761083 PINION SHAFT
31 P0761031 IDLER SHAFT 84 P0761084 LEVER HUB
32 P0761032 GEAR 29T 85 P0761085 SPRING BASE
33 P0761033 GEAR 35T 86 P0761086 SPRING COVER
34 P0761034 GEAR 21T 87 P0761087 COILED SPRING
35 P0761035 GEAR 41T 88 P0761088 KNOB BOLT M10-1.5 X 45
36 P0761036 BALL BEARING 6202-OPEN P5 89 P0761089 COMPRESSION SPRING
37 P0761037 KEY 6 X 6 X 14 90 P0761090 FINE DOWNFEED GRADUATED DIAL
38 P0761038 KEY 6 X 6 X 28 91 P0761091 SHOULDER STUD-UDE M12-1.75 X 145 15,20
39 P0761039 STEEL BALL 8MM 92 P0761092 TAPERED KNOB M12-1.75
40 P0761040 COMPRESSION SPRING 93 P0761093 FINE DOWNFEED HANDWHEEL
41 P0761041 EXT RETAINING RING 18MM 94 P0761094 HANDWHEEL HANDLE
42 P0761042 KEY 5 X 5 X 50 95 P0761095 CAP SCREW M8-1.25 X 25
43 P0761043 SET SCREW M6-1 X 12 96 P0761096 KNURLED THUMB SCREW M5-.8 X 12
44 P0761044 SPINDLE SHAFT 97 P0761097 SPRING COVER FLAT WASHER 6MM
To Next Page
