PAGE 1 OF 2Model G0761
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0761 HEAVY-DUTY BENCHTOP MILL/DRILL WITH
POWER FEED AND TAPPING
Product Dimensions:
Weight.............................................................................................................................................................. 716 lbs.
Width (side-to-side) x Depth (front-to-back) x Height............................................................... 49-5/8 x 30-3/4 x 57 in.
Footprint (Length x Width)............................................................................................................... 21-5/8 x 17-3/4 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 772 lbs.
Length x Width x Height....................................................................................................................... 34 x 30 x 46 in.
Electrical:
Power Requirement............................................................................................................ 220V, Single-Phase, 60Hz
Prewired Voltage.................................................................................................................................................. 220V
Full-Load Current Rating....................................................................................................................................... 8.6A
Minimum Circuit Size.............................................................................................................................................. 15A
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 5 ft.
Power Cord Gauge......................................................................................................................................... 14 AWG
Plug Included........................................................................................................................................................... No
Recommended Plug Type..................................................................................................................................... 6-15
Switch Type........................................................................................... Control Panel w/ Magnetic Switch Protection
Motors:
Main
Type................................................................................................................. TEFC Capacitor-Start Induction
Horsepower................................................................................................................................................ 2 HP
Phase............................................................................................................................................ Single-Phase
Amps........................................................................................................................................................... 8.6A
Speed................................................................................................................................................ 1720 RPM
Power Transfer ................................................................................................................................. Gear Drive
Bearings..................................................................................................... Shielded & Permanently Lubricated
Main Specifications:
Operation Info
Spindle Travel........................................................................................................................................ 4-3/4 in.
Max Distance Spindle to Column........................................................................................................ 10-1/8 in.
Max Distance Spindle to Table............................................................................................................ 18-1/8 in.
Longitudinal Table Travel (X-Axis).............................................................................................................. 22 in
Cross Table Travel (Y-Axis).................................................................................................................. 7-1/2 in.
Vertical Head Travel (Z-Axis)............................................................................................................... 13-3/4 in
Head Tilt (Left/Right)........................................................................................................ Right 45, Left 45 deg.
Drilling Capacity for Cast Iron................................................................................................................ 1-3/4 in.
Drilling Capacity for Steel...................................................................................................................... 1-1/4 in.
End Milling Capacity............................................................................................................................. 1-1/4 in.
Face Milling Capacity............................................................................................................................ 3-1/8 in.
Machine Data Sheet

Grizzly G0761 Specifications

General

Brand	Grizzly
Model	G0761
Category	Drill
Language	English
