Model G0761 (Mfd. Since 10/13)
-47-
Table & Column Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
201 P0761201 BASE 248 P0761248 X-AXIS GIB
202 P0761202 COLUMN 249 P0761249 CAP SCREW M8-1.25 X 25
203 P0761203 Y-AXIS LEADSCREW BRACKET 252 P0761252 Y-AXIS GIB
204 P0761204 HEADSTOCK MOUNT 254 P0761254 Z-AXIS CRANK SHAFT BRACKET
205 P0761205 Z-AXIS GIB 255 P0761255 Z-AXIS CRANK SHAFT
206 P0761206 GIB ADJUSTMENT SCREW 256 P0761256 WORM GEAR
207 P0761207 THRUST BEARING 51103 257 P0761257 BALL BEARING 6004ZZ
208 P0761208 Y-AXIS LEADSCREW 258 P0761258 SPACER
209 P0761209 DIAL CLUTCH 259 P0761259 CRANK SHAFT END FLANGE ASSY
210 P0761210 GRADUATED DIAL 260 P0761260 Z-AXIS LEADSCREW
211 P0761211 HANDWHEEL 261 P0761261 THRUST BEARING 51104
212 P0761212 HANDWHEEL HANDLE W/SCREW 262 P0761262 KEY 6 X 6 X 20
214 P0761214 Z-AXIS LEADSCREW NUT 263 P0761263 SPANNER NUT LOCK WASHER 20MM
215 P0761215 Z-AXIS LEADSCREW NUT BRACKET 264 P0761264 SPANNER NUT M20-1.5
216 P0761216 COLUMN TOP COVER 265 P0761265 CAP SCREW M6-1 X 20
217 P0761217 CAP SCREW M8-1.25 X 20 266 P0761266 WORM GEAR FLAT WASHER 8MM
218 P0761218 CAP SCREW M8-1.25 X 25 267 P0761267 CAP SCREW M8-1.25 X 16
219 P0761219 ROLL PIN 5 X 35 268 P0761268 Z-AXIS CRANK HANDLE ASSY
220 P0761220 KNURLED THUMB SCREW M5-.8 X 12 271 P0761271 T-BOLT M14-2 X 55
221 P0761221 BALL OILER 8MM TAP-IN 272 P0761272 FLAT WASHER 14MM
222 P0761222 ADJUSTMENT HANDLE M8-1.25 273 P0761273 HEX NUT M14-2
223 P0761223 LOCK WASHER 16MM 274 P0761274 POWER FEED ASSY ALIGN AS-235
224 P0761224 FLAT WASHER 16MM 274-1 P0761274-1 MOUNTING BRACKET 2-PC
225 P0761225 CAP SCREW M16-2 X 60 274-2 P0761274-2 CONTROL HANDLE
226 P0761226 HEADSTOCK MOUNT FLAT WASHER 12MM 274-3 P0761274-3 SPEED CONTROL KNOB
227 P0761227 CAP SCREW M12-1.75 X 35 274-4 P0761274-4 ON/OFF SWITCH
228 P0761228 COLUMN REAR COVER 274-5 P0761274-5 ZYTEL GEAR ASSEMBLY
229 P0761229 COLUMN FRONT COVER 275 P0761275 CAP SCREW M8-1.25 X 6
230 P0761230 BUTTON HD CAP SCR M6-1 X 12 276 P0761276 FLAT WASHER 8MM
231 P0761231 ROLL PIN 8 X 30 277 P0761277 POWER FEED LIMIT SWITCH
233 P0761233 COOLANT DRAIN SCREEN 278 P0761278 EXT RETAINING RING 8MM
234 P0761234 PHLP HD SCR M3-.5 X 25 279 P0761279 SQUARE NUT M8-1.25
235 P0761235 SADDLE 280 P0761280 POWER FEED LIMIT STOP
236 P0761236 TABLE 281 P0761281 COMPRESSION SPRING
237 P0761237 X-AXIS LEADSCREW NUT 282 P0761282 LIMIT STOP HOUSING
238 P0761238 Y-AXIS LEADSCREW NUT 283 P0761283 PHLP HD SCR M4-.7 X 6
239 P0761239 X-AXIS LEADSCREW BRACKET (RH) 284 P0761284 Z-AXIS WAY COVER UPPER PLATE
240 P0761240 X-AXIS LEADSCREW BRACKET (LH) 285 P0761285 Z-AXIS WAY COVER
241 P0761241 X-AXIS LEADSCREW 286 P0761286 Z-AXIS WAY COVER LOWER BRACKET
242 P0761242 CAP SCREW M6-1 X 16 287 P0761287 PHLP HD SCR M5-.8 X 12
244 P0761244 FLAT WASHER 6MM 288 P0761288 Y-AXIS WAY COVER
245 P0761245 CAP SCREW M5-.8 X 20 289 P0761289 TABLE SCALE
246 P0761246 CAP SCREW M8-1.25 X 45
