-28-
Model G0781 (Mfd. Since 2/15)
SB1348—South Bend
®
8-Pc. R-8 Collet Set
SB1349—South Bend
®
16-Pc. R-8 Collet Set
Get true South Bend
®
quality and precision with
one of these Quick-Change Collet Sets. Each set
includes hardened and precision-ground spring
collets for maximum holding power, collet chuck,
spanner wrench, and protective moulded case.
Figure 30. Model SB1349 South Bend 16-Pc.
R-8 Collet Set.
G5758—5" x 7" x 3
3
⁄4" Tilt Table
G5759—7" x 10" x 5" Tilt Table
Set your work at any angle from -45° to +45° with
these sturdy Tilt Tables. Heavy-duty construction
includes
7
⁄16" T-slots, two locking screws, and pre-
cision base.
1
⁄2" mounting slots.
Figure 33. G5758 Tilt Table.
Figure 31. T24799 and T24800 Precision
Parallel Blocks.
T24799—1-2-3 Precision Parallel Blocks
T24800—2-4-6 Precision Parallel Blocks
These blocks are extremely handy for layout and
set up work. Matched blocks are hardened and
precision ground so all six sides are square to
within 0.0003".
T24800
T24799
Figure 32. H7527 6" Rotary Table w/Div. Plates.
H7527—6" ROTARY TABLE SET
Use this 6" Rotary Table in either the horizontal
or vertical position for a variety of milling appli-
cations and with the set of dividing plates and
adjustable tailstock, your milling applications are
nearly unlimited. With 4° table movement per han-
dle rotation and 20 second vernier scale, control
is very accurate and precise. Also includes a
3
⁄8"
clamping set for the 4-slot table. Everything you
need in one great set!
