Grizzly G0781 User Manual

-40-
Model G0781 (Mfd. Since 2/15)
READ ELECTRICAL SAFETY
ON PAGE 38!
DRO
L2
A-
F-
F+
L1
A+
P1
P2
P3
To Plug
ON/OFF Switch
3
1
4
2
B4K7
Mornsun
LD01-10B05
Capacitor
110 VAC
Neutral
Hot
Ground
5-15 Plug
(Pre-Wired)
Rear Panel
Front Panel
(Viewed From Backside)
Side Panel
(Viewed From Backside)
Bottom Inside Panel
(Viewed From Backside)
JD011
J2 J1
Power
Light
110V
FWD/REV Switch
E-TEN1322 15A/250VAC
Potentiometer
Circuit Board
JD-111 REVA 141022
Mill/Drill
Motor
120V 5A
Single Phase
3/4 HP
5000 RPM
KEDU
KJD12
120V
FUSE 8AL250V
RPM
Sensor
Wiring Diagram
