Grizzly G0781 User Manual

Model G0781 (Mfd. Since 2/15)
-5-
The information contained herein is deemed accurate as of 4/15/2019 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 2
Model G0781
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G0781 4" X 18" 3/4 HP MILL/DRILL
Product Dimensions:
Weight.............................................................................................................................................................. 137 lbs.
Width (side-to-side) x Depth (front-to-back) x Height............................................................... 26-1/2 x 20-1/2 x 31 in.
Footprint (Length x Width)................................................................................................................. 14-1/2 x 8-1/2 in.
Shipping Dimensions:
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 167 lbs.
Length x Width x Height....................................................................................................................... 25 x 22 x 29 in.
Must Ship Upright................................................................................................................................................... Yes
Electrical:
Power Requirement............................................................................................................ 110V, Single-Phase, 60Hz
Full-Load Current Rating.......................................................................................................................................... 5A
Minimum Circuit Size.............................................................................................................................................. 15A
Connection Type....................................................................................................................................... Cord & Plug
Power Cord Included.............................................................................................................................................. Yes
Power Cord Length................................................................................................................................................. 6 ft.
Power Cord Gauge......................................................................................................................................... 18 AWG
Plug Included.......................................................................................................................................................... Yes
Included Plug Type................................................................................................................................................ 5-15
Switch Type.......................................................................................... ON/OFF Push Button Switch w/Safety Cover
Motors:
Main
Horsepower................................................................................................................................ 600W (3/4 HP)
Phase............................................................................................................................................ Single-Phase
Amps.............................................................................................................................................................. 5A
Speed................................................................................................................................................ 5000 RPM
Type....................................................................................................................... Universal Brush-Type Motor
Power Transfer ................................................................................................................................. Gear Drive
Bearings.................................................................................................... Shielded & Permanently Lubricated
Centrifugal Switch/Contacts Type................................................................................................................ N/A
Main Specifications:
Operation Info
Max Distance Spindle to Column.......................................................................................................... 6-3/8 in.
Max Distance Spindle to Table............................................................................................................ 11-1/2 in.
Longitudinal Table Travel (X-Axis).................................................................................................. 11-13/16 in.
Cross Table Travel (Y-Axis).................................................................................................................. 5-1/8 in.
Vertical Head Travel (Z-Axis).............................................................................................................. 7-1/16 in.
Head Tilt (Left/Right).............................................................................................................................. 45 deg.
Drilling Capacity for Cast Iron................................................................................................................... 1/2 in.
Drilling Capacity for Steel......................................................................................................................... 1/2 in.
End Milling Capacity................................................................................................................................. 1/2 in.
Face Milling Capacity................................................................................................................................... 1 in.
