Grizzly G0785 - Wiring Diagram

-28-
Model G0785 (Mfd. Since 3/15)
READ ELECTRICAL SAFETY
ON PAGE 27!
Wiring Diagram
120 Volt Motor
Ground
240 Volt Motor
Ground
Wt
Start
Capacitor
200MFD
125VAC
Run
Capacitor
30MFD
250VAC
Start
Capacitor
200MFD
125VAC
Run
Capacitor
30MFD
250VAC
Wt
Wt
Wt
Wt
Wt
Safety Paddle Switch
Grizzly Model G8988
Safety Paddle Switch
Grizzly Model G8988
6-15 Plug
(As Recommended)
Hot
Hot
Ground
240
VAC
G
Neutral
Hot
Ground
120 VAC
5-15 Plug
(Pre-Wired)
240 VAC
Figure 25. Start
capacitor.
Figure 26. 120V
junction box.
Figure 27. 240V
junction box.
