-30 -
Model G0785 (Mfd. Since 3/15)
Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0785001 CANISTER FILTER 20 P0785020 HEX BOLT M6-1 X 16
1-1 P0785001-1 FLANGE GASKET (FOAM) 21 P0785021 PHLP HD SCR M5-.8 X 10
2 P0785002 MAIN SPINDLE 22 P0785022 PHLP HD SCR M5-.8 X 15
3 P0785003 BEARING PLATE 23 P0785023 FLAT WASHER 1/4
4 P0785004 CRANK SPI NDLE 24 P0785024 PHLP HD SCR M6-1 X 12
5 P0785005 BEVEL GEAR 25 P0785025 FLANGE SCREW 1/4-20 X 1/2
6 P0785006 BUSHING 26 P0785026 HEX BOLT 1/4-20 X 1/2
7 P0785007 IMPELLER HOUSING 27 P0785027 FLANGE SCREW 1/4-20 X 3/4
8 P0785008 INLET COVER 28 P0785028 PHLP HD SCR M5-.8 X 8
9 P0785009 ALUMINIUM IMPELLER 10" 29 P0785029 COLLECTION BAG 22-3/4" X 30"
10 P0785010 MOTOR 1HP 120/240V 1-PH 30 P0785030 SET SCREW 1/4-20 X 5/16
10-1 P0785010-1 MOTOR JUNCTION BOX 31 P0785031 LOCK WASHER 1/4
10-2 P0785010-2 S CAPACITOR 200M 125V 1-3/8 X 2-3/4 32 P0785032 MOTOR GASKET
10-3 P0785010-3 FAN COVER 33 P0785033 CRANK HANDLE M10-1.5 X 14, 98L
10-4 P0785010-4 MOTOR FAN 34 P0785034 LOCK NUT M10-1.5
10-5 P0785010-5 R CAPACITOR 30M 250V 1-3/8 X 2-1/2 35 P0785035 HAND GRIP 1 X 5" (FOAM)
10-6 P0785010-6 CAPACITOR COVER 36 P0785036 END CAP 1"
10-7 P0785010-7 BALL BEARING 6203ZZ (FRONT) 37 P0785037 SPINDLE BRACKET
10-8 P0785010-8 BALL BEARING 6202ZZ (REAR) 39 P0785039 HEX NUT M5-. 8
10-9 P0785010-9 CENTRUFUGAL SWI TCH 40 P0785040 SET SCREW 5/16-18 X 5/16
10-10 P0785010-10 CONTACT PLATE 41 P0785041 MOUNTING PLATE
11 P0785011 MOTOR MOUNTI NG PLATE 42 P0785042 GASKET (RUBBER)
12 P0785012 WALL MOUNTING BRACKET 43 P0785043 OUTLET DIRECTION LABEL
13 P0785013 CLEANOUT CRANK HANDLE 44 P0785044 READ MANUAL LABEL
14 P0785014 IMPELLER WASHER 6MM 45 P0785045 EYE/LUNG INJURY HAZARD LABEL
15 P0785015 CAP SCREW M6-1 X 30 LH 46 P0785046 AMPUTATION HAZARD LABEL
16 P0785016 BAG CLAMP 47 P0785047 ELECTRICITY LABEL
17 P0785017 CLEANOUT FLAPPER 48 P0785048 MACHINE ID LABEL
18 P0785018 BEARING PLATE 49 P0785049 TOUCH-UP PAINT, GRIZZLY BEIGE
19 P0785019 PHLP HD SCR M5-.8 X 10
