G0890/G0891 (Mfd. Since 06/19)
-35-
Drive Chain & Sprockets
Grease Type ............... T26419 Synthetic Grease
Frequency
............ Every 160 Hours of Operation
The infeed and outfeed rollers receive the trans-
ferred power from the cutterhead through the drive
chain system on the right side of the machine, as
shown in Figure 36. Remove the gearbox cover
to access these parts.
Use shop rags and mineral spirits to clean away
any debris and grime, then brush on a light coat of
multi-purpose grease to the chain and sprockets.
Figure 36. Drive chains and sprockets for infeed
and outfeed rollers.
Gearbox Oil
Oil Type .............. T28042 or ISO-320 Equivalent
Oil Amount
.................................................20 Oz.
Frequency
....... After First 20 Hours, Then Yearly
Note: We recommend that you replace the gear-
box oil after the first 20 hours of operation. This is
a normal break-in procedure and will help maxi-
mize the service life of the machine by flushing
away any particles from the break-in and manu-
facturing process.
Although it is not necessary to remove the gear-
box cover to access the fill and drain plugs, it is
more convenient to do so (see Figures 37–38).
Replace the gearbox oil with ISO 320 or equiva-
lent oil until it just reaches the fill plug.
Figure 37. Location of gearbox drain plug.
Figure 38. Example of gearbox fill plug.
Fill Plug
Drain Plug
