-48-
G0890/G0891 (Mfd. Since 06/19)
READ ELECTRICAL SAFETY
ON PAGE 47!
G0890/G0891 Wiring Diagram
The motor wiring shown here is
current at the time of printing, but it
may not match your machine.
Always use the wiring diagram
inside the motor junction box.
A
96
98
1/2
T1/2 T3/6
NO14
3/4
T2/4
L1/1 L3/5
NO13
L2/3
5/6
95
12
ARC
AMP
18
15
NC21
SDE
NC22
Ground
RESET
MAGNETIC SWITCH
ASSEMBLY SDE MP-18
SDE
MA-18
240V
RA-20
Hot
Hot
Ground
6-20 Plug
230
VAC
B
GND
Start Capacitor
400MFD
125VAC
70uF
250VAC
Run Capacitor
G
MOTOR (230V)
