Grizzly G0890 User Manual

-56-
G0890/G0891 (Mfd. Since 06/19)
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
WARNING!
EYE/EAR/LUNG
INJURY HAZARD!
Always wear safety
glasses, ear protection,
and respirator when
using this machine.
REFER TO
OWNER’S MANUAL
FOR OIL TYPE AND
AMOUNT.
CHECK OIL
LEVEL BEFORE USING!
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual, call
(800) 523-4777 or go to
www.grizzly.com.
INJURY/SHOCK
HAZARD!
Disconnect power
before adjustments,
maintenance, or
service.
Add SAE 30 oil every 24 hours of operation.
NOTICE
grizzly.com
INJURY HAZARD!
To reduce the risk of serious personal
injury, do not remove this cover while the
machine is running or connected to power.
Always disconnect power before servicing.
WARNING!
INJURY HAZARD!
To reduce risk of short
and long-term injury,
wear safety glasses,
hearing protection, and
a respirator when using
this machine.
301
Motor: 3 HP, 230V, 1-Ph, 60 Hz, 12A
Cutterhead: 3 Knife, 2-5/8" Dia.
Knife Size: 15" x 1" x 1/8"
Replacement Knives: G6701
Cutterhead Speed: 5200 RPM
Feed Rates: 16, 28 FPM
Max. Depth of Cut: 1/8"
Min. Stock Thickness: 3/16"
Min. Stock Length: 6"
Max. Cutting Width: 15"
Max. Cutting Height: 6"
Weight: 300 lbs.
MODEL G0890
15" 3 HP FIXED-TABLE PLANER
Specifications
WARNING!
Date
Mfd. for Grizzly in Taiwan
S/N
To reduce the risk of serious injury when using this machine:
1. Read and understand owner’s manual before operating.
2. Always wear approved safety glasses and respirator.
3. Disconnect power before changing blades, removing
parts, or doing maintenance, service, or adjustments.
4. Only plug power cord into a grounded outlet.
5. Do not wear loose clothing, gloves, jewelry, or other items
that can get entangled. Tie back long hair and roll up sleeves.
6. Ensure machine is correctly set up before starting.
7. Do not plane two boards of varying thickness at same time.
8. Never plane material smaller than 6" long or
3
/
16
" thick.
9. Keep fingers clear of pinch point between stock and table.
.noitarepo gnittuc gnirud sdne draob fo raelc dnatS .01
.gnicivres nehw noituac emertxe esU !prahs era sevinK .11
12. Never reach into cutting area while machine is running.
.snoitacol tew ro pmad ni esu ro niar ot esopxe ton oD .31
14. Prevent unauthorized use by children or untrained users.
175370
302
303
304
305
306
307
308
309
310
311
312
313
Motor: 3 HP, 230V, 1-Ph, 60 Hz, 12A
Cutterhead: 4 Spirals, 48 Inserts
Insert Size: 15 x 15 x 2.5mm
Replacement Inserts: H9893
Cutterhead Speed: 5200 RPM
Feed Rates: 16, 28 FPM
Max. Depth of Cut: 1/8"
Min. Stock Thickness: 3/16"
Min. Stock Length: 6"
Max. Cutting Width: 15"
Max. Cutting Height: 6"
Weight: 302 lbs.
Specifications
WARNING!
Date
Mfd. for Grizzly in Taiwan
S/N
To reduce the risk of serious injury when using this machine:
1. Read and understand owner’s manual before operating.
2. Always wear approved safety glasses and respirator.
3. Disconnect power before changing inserts, removing
parts, or doing maintenance, service, or adjustments.
4. Only plug power cord into a grounded outlet.
5. Do not wear loose clothing, gloves, jewelry, or other items
that can get entangled. Tie back long hair and roll up sleeves.
6. Ensure machine is correctly set up before starting.
7. Do not plane two boards of varying thickness at same time.
8. Never plane material smaller than 6" long or
3
/
16
" thick.
9. Keep fingers clear of pinch point between stock and table.
10. Stand clear of board ends during cutting operation.
11. Inserts are sharp! Use extreme caution when servicing.
12. Never reach into cutting area while machine is running.
13. Do not expose to rain or use in damp or wet locations.
14. Prevent unauthorized use by children or untrained users.
175370
MODEL G0891
15" 3 HP FIXED-TABLE PLANER
w/HELICAL CUTTERHEAD
G0891
G0890
Labels & Cosmetics
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P0890301 DISCONNECT POWER LABEL 308 P0890308 INJURY HAZARD LABEL
302 P0890302 MACHINE ID LABEL (G0890) 309 P0890309 EYE/EAR/LUNG LABEL
302 P0891302 MACHINE ID LABEL (G0891) 310 P0890310 GRIZZLY.COM LABEL
303 P0890303 READ MANUAL LABEL 311 P0890311 GRIZZLY NAMEPLATE–LARGE
304 P0890304 ADD OIL LABEL 312 P0890312 MODEL NUMBER LABEL (G0890)
305 P0890305 STOP OIL FILL TAG 312 P0891312 MODEL NUMBER LABEL (G0891)
306 P0890306 ELECTRICITY LABEL 313 P0890313 TOUCH-UP PAI NT, GRI ZZLY BEI GE
307 P0890307 TOUCH-UP PAI NT, GRI ZZLY GREEN
