Table Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
200 P0890200 LEADSCREW 217 P0890217 EXT RETAI NI NG RI NG 15MM
201 P0890201 SPROCKET 218 P0890218 HEX BOLT M8-1.25 X 25
202 P0890202 FLAT WASHER 10MM 219 P0890219 SLEEVE
203 P0890203 HEX NUT M10-1.25 221 P0890221 FLAT WASHER 8MM
204 P0890204 DEPTH-OF-CUT SCALE 222 P0890222 CHAIN 410 X 148P
205 P0890205 PHLP HD SCR M3-.5 X 4 223 P0890223 HEX NUT M10-1.25
206 P0890206 HANDWHEEL TYPE-3 216D X 10B-K X M10-1.5 224 P0890224 FLAT WASHER 10MM
207 P0890207 KEY 4 X 4 X 20 225 P0890225 DIRECTION LABEL
208 P0890208 SET SCREW M10-1.5 X 12 226 P0890226 HEX BOLT M8-1.25 X 25
209 P0890209 COLUMN 227 P0890227 SET SCREW M8-1.25 X 20
210 P0890210 LEADSCREW 245 P0890245 REVOLVING HANDLE 24 X 92, M10-1.5 X 12
211 P0890211 CAP 246 P0890246 LEADSCREW MOUNT
212 P0890212 CAST IRON EXTENSION TABLE 293 P0890293 MAIN TABLE
212-1 P0890212-1 HEX BOLT M8-1.25 X 25 294 P0890294 HEX BOLT M8-1.25 X 45
212-2 P0890212-2 SET SCREW M8-1.25 X 20 295 P0890295 COLUMN
212-3 P0890212-3 CAST IRON EXTENSION TABLE 296 P0890296 BUSHI NG
214 P0890214 BRACKET 297 P0890297 I NT RETAI NI NG RING 38MM
215 P0890215 SHAFT 298 P0890298 BALL BEARING 6202Z
216 P0890216 SPROCKET 299 P0890299 I NT RETAI NI NG RING 35MM
