Grizzly G0890 User Manual

G0890/G0891 (Mfd. Since 06/19)
-51-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Headstock Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0890001 HEADSTOCK 57-3 P0890057-3 GIB
2 P0890002 SHAFT 57-4 P0890057-4 GIB SCREW
3 P0890003 ANTI-KICKBACK FINGER 57-5 P0890057-5 ADJ USTMENT SCREW M5-. 8 X 12
4 P0890004 COLLAR 57 P0891057 CUTTERHEAD ASSEMBLY (G0891)
5 P0890005 POLY V-BELT 360J-9 57-1 P0891057-1 HELI CAL CUTTERHEAD 15"
6 P0890006 INFEED ROLLER 57-2 P0891057-2 FLATHEAD TORX 10-32 X 1/2
7 P0890007 ROLLER SEAT 57-3 P0891057-3 CARBIDE INSERT 15 X 15 X 2.5MM 10-PK
8 P0890008 SPROCKET 58 P0890058 BALL BEARING 6204-2NSE
9 P0890009 FLAT WASHER 6MM 59 P0890059 GEAR
10 P0890010 HEX BOLT M6-1 X 16 60 P0890060 PULLEY (G0890)
11 P0890011 OUTFEED ROLLER 60 P0890060 PULLEY (G0891)
12 P0890012 COLLECTOR HOOD 61 P0890061 KEY 6 X 6 X 20 (G0890)
13 P0890013 CHIP BREAKER 61 P0891061 KEY 6 X 6 X 30 (G0891)
16 P0890016 TOP COVER 62 P0890062 FLAT WASHER 8MM
17 P0890017 CLAMP 64 P0890064 BUTTON HD CAP SCR M8-1.25 X 20
18 P0890018 HEX BOLT M6-1 X 12 65 P0890065 GEAR BOX
19 P0890019 DEFLECTOR PLATE 66 P0890066 GEAR BOX COVER
20 P0890020 SPRING 67 P0890067 GASKET
23 P0890023 BUTTON HD CAP SCR M6-1 X 12 68 P0890068 OIL SEAL 28 X 40 X 8
24 P0890024 BUTTON HD CAP SCR M6-1 X 20 69 P0890069 BALL BEARING 6201-2NSE
25 P0890025 SET SCREW M6-1 X 16 70 P0890070 SHAFT
26 P0890026 BUTTON HD CAP SCR M6-1 X 25 71 P0890071 GEAR 52T
27 P0890027 FLAT WASHER 6MM 72 P0890072 KEY 5 X 5 X 12
28 P0890028 SET SCREW M6-1 X 30 73 P0890073 SHAFT
29 P0890029 HEX NUT M6-1 (NYLON) 74 P0890074 GEAR
30 P0890030 BUTTON HD CAP SCR M8-1.25 X 25 75 P0890075 KEY 5 X 5 X 10
31 P0890031 DRIVE CHAIN COVER 76 P0890076 SHAFT
32 P0890032 BUTTON HD CAP SCR M6-1 X 12 77 P0890077 GEAR ASSEMBLY
33 P0890033 BUTTON HD CAP SCR M6-1 X 16 78 P0890078 KEY 6 X 6 X 40
34 P0890034 BRACKET 79 P0890079 SPRI NG
35 P0890035 PHLP HD SCR M6-1 X 12 80 P0890080 STEEL BALL 6MM
37 P0890037 BUTTON HD CAP SCR M5-. 8 X 12 81 P0890081 OIL SEAL 25 X 47 X 6
38 P0890038 SPRING 82 P0890082 OIL SEAL P12
39 P0890039 HEX NUT M5-. 8 83 P0890083 SPROCKET
40 P0890040 SHOULDER BOLT M8-1.25 X 14, 4 X 12 84 P0890084 PIN
41 P0890041 SPRING 85 P0890085 BUTTON HD CAP SCR M6-1 X 25
42 P0890042 PLATE 86 P0890086 OIL PLUG 1/4
43 P0890043 SET SCREW M6-1 X 20 87 P0890087 CLUTCH FORK
44 P0890044 HEX NUT M6-1 88 P0890088 HANDLE
45 P0890045 POINTER 89 P0890089 KNOB 3/8-16, D1-1/4, BALL
46 P0890046 RIVET 2.5MM X 8MM 90 P0890090 CHAIN 06B X 41P
47 P0890047 TENSION BOLT 91 P0890091 CHAIN 06B X 50P
48 P0890048 EXT RETAI NI NG RI NG 47MM 113 P0890113 WAVY WASHER 8MM
57 P0890057 CUTTERHEAD ASSEMBLY (G0890) 147 P0890147 HEX BOLT M6-1 X 12
57-1 P0890057-1 CUTTERHEAD 15" 3-KNI FE 193 P0890193 FLAT WASHER 6MM
57-2 P0890057-2 PLANER BLADE 15" X 1" X 1-1/8"
