Grizzly G0890 User Manual

G0890/G0891 (Mfd. Since 06/19)
-53-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Stand & Motor Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P0890101 SWI TCH CORD 12G 3W 34" 133-5 P0890133-5 MOTOR FAN
102 P0890102 POWER CORD 12G 3W 150" 6-20P 133-6 P0890133-6 R CAPACITOR 70M 250V 1-9/16 X 3-1/2
103 P0890103 STRAIN RELIEF TYPE-3 PG13.5 133-7 P0890133-7 S CAPACITOR 400M 125V 1-9/16 X 3-1/2
104 P0890104 STRAIN RELIEF TYPE-1 1/2 133-8 P0890133-8 CENTRI FUGAL SWITCH
105 P0890105 MOUNTI NG PLATE 133-9 P0890133-9 CONTACT PLATE
106 P0890106 MOTOR CORD 12G 3W 24" 133-10 P0890133-10 BALL BEARING 6205ZZ (FRONT)
107 P0890107 KEY 6 X 6 X 18 133-11 P0890133-11 BALL BEARING 6203ZZ (REAR)
108 P0890108 FLAT WASHER 8MM 135 P0890135 PHLP HD SCR M6-1 X 12
109 P0890109 MOTOR PULLEY 136 P0890136 PHLP HD SCR M3-.5 X 10
110 P0890110 BUTTON HD CAP SCR M8-1.25 X 20 139 P0890139 CAP SCREW M6-1 X 16
111 P0890111 STRAIN RELIEF TYPE-1 1/2 143 P0890143 FLAT WASHER 6MM
114 P0890114 COVER MOUNT 144 P0890144 GAS STRUT
115 P0890115 STRUT MOUNT 146 P0890146 PHLP HD SCR M5-.8 X 10
120 P0890120 SET SCREW M8-1.25 X 35 147 P0890147 HEX BOLT M6-1 X 12
121 P0890121 FLAT WASHER 8MM 148 P0890148 HEX WRENCH 4MM
122 P0890122 FLAT WASHER 10MM PLASTIC 149 P0890149 BELT COVER
123 P0890123 GAS STRUT 150 P0890150 MOTOR PLATE
124 P0890124 STAND 151 P0890151 BUTTON HD CAP SCR M6-1 X 20
125 P0890125 MAGNETIC SWITCH ASSY MP-18 152 P0890152 BUTTON HD CAP SCR M8-1.25 X 20
125-1 P0890125-1 MAGNETI C SWI TCH COVER (FRONT) 153 P0890153 BUTTON HD CAP SCR M8-1.25 X 25
125-2 P0890125-2 MAGNETI C SWI TCH COVER (REAR) 154 P0890154 SLEEVE
125-3 P0890125-3 CONTACTOR SDE MA-18 220V-240V 155 P0890155 HEX NUT M8-1.25 NYLON
125-4 P0890125-4 OL RELAY SDE RA-20 12-18A 156 P0890156 FLAT WASHER 8MM
126 P0890126 FOOT M8-1.25 X 60 157 P0890157 OPEN-END WRENCH 10/13MM
127 P0890127 HEX NUT M8-1. 25 158 P0890158 OPEN-END WRENCH 12/ 14MM
128 P0890128 CABLE PROTECTOR 159 P0890159 OPEN-END WRENCH 17/ 19MM
129 P0890129 ACCESS PANEL 160 P0890160 BRACKET
130 P0890130 T-HANDLE TORX DRI VER T-25 161 P0890161 FLAT WASHER 6MM
131 P0890131 PLATE 162 P0890162 FLAT WASHER 8MM
132 P0890132 ADJUSTABLE BRACKET 163 P0890163 T-HANDLE TORX DRIVER T-30
133 P0890133 MOTOR 3HP 230V 1PH 192 P0890192 KNIFE SETTING JIG (G0890)
133-1 P0890133-1 MOTOR FAN COVER 193 P0890193 FLAT WASHER 6MM
133-2 P0890133-2 RUN CAPACI TOR COVER 194 P0890194 LOCK WASHER 6MM
133-3 P0890133-3 START CAPACITOR COVER 195 P0890195 LOCK WASHER 8MM
133-4 P0890133-4 MOTOR J UNCTI ON BOX 196 P0890196 SPRING WASHER 6MM
