REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0945001 TABLE 62 P0945062 RIGHT BASE PANEL
2 P0945002 CAP SCREW M8-1.25 X 30 64 P0945064 HEX NUT M8-1. 25
3 P0945003 OUTFEED TABLE SUPPORT 70 P0945070 PUSH BLOCK
4 P0945004 SET SCREW M6-1 X 8 71 P0945071 HEX WRENCH 2. 5MM
5 P0945005 DUST CHUTE COVER 72 P0945072 HEX WRENCH 4MM
6 P0945006 BUTTON HD CAP SCR M6-1 X 12 73 P0945073 EXT TOOTH WASHER 5MM
7 P0945007 TAP SCREW 1/4 X 5/8 74 P0945074 HEX NUT M5-. 8
9 P0945009 FOAM SEAL 75 P0945075 LOCK NUT M5-. 8
10 P0945010 DUST CHUTE 100 P0945100 ROUND PLUG 42MM
12 P0945012 FRONT BASE PANEL 101 P0945101 CUTTERHEAD GUARD
13 P0945013 DUST PORT 2-1/2" 103 P0945103 RUBBER BUMPER
14 P0945014 FRONT BEARING RETAINER 104 P0945104 TORSION SPRING 1.6 X 23MM
16 P0945016 BALL BEARING 6201ZZ 105 P0945105 GUARD MOUNTI NG BRACKET
17 P0945017 EXT RETAINI NG RING 12MM 106 P0945106 E-CLIP 10MM
18 P0945018 CUTTERHEAD LOCK 125 P0945125 FENCE
20 P0945020 SCALE POINTER 128 P0945128 TILT BRACKET
21 P0945021 SCALE GEAR 129 P0945129 T-SLOT NUT 7, M6-1
22 P0945022 SCALE PLATE 130 P0945130 SQUARE NUT M8-1.25
23 P0945023 KNOB BOLT M8-1.25 X 18, 12-LOBE, D49 131 P0945131 SET SCREW M5-.8 X 8
24 P0945024 FENDER WASHER 8MM 132 P0945132 TILT SUPPORT BRACKET
25 P0945025 FOOT PAD 133 P0945133 ADJ HANDLE M8-1.25 X 30, 50L
26 P0945026 EXT RETAINI NG RING 16MM 135 P0945135 ADJ HANDLE M8-1.25 X 40, 50L
27 P0945027 PHLP HD SCR M5-.8 X 8 136 P0945136 FENCE SLIDE BRACKET
28 P0945028 BUTTON HD CAP SCR M5-. 8 X 25 137 P0945137 FENCE SUPPORT BRACKET
29 P0945029 PADDLE SWITCH BOX 138 P0945138 FLAT WASHER 6MM
34 P0945034 REAR BASE PANEL 139 P0945139 BUTTON HD CAP SCR M6-1 X 16
35 P0945035 ROUND PLUG 35MM 160 P0945160 CUTTERHEAD ASSEMBLY
36 P0945036 REAR BEARING RETAINER 160-3 P0945160-3 BUTTON HD CAP SCR 1/4-20 X 5/8
38 P0945038 MOTOR PULLEY 160-4 P0945160-4 KNIFE CLAMP BAR
39 P0945039 CUTTERHEAD PULLEY 160-5 P0945160-5 JOINTER KNIFE 6-1/4" X 7/8" X 1/16" 2-PK
40 P0945040 POLY-V BELT 125J5 160-6 P0945160-6 SPACER 12ID X 16OD X 4L
41 P0945041 BELT COVER 160-7 P0945160-7 CUTTERHEAD 6" 2-KNI FE
48 P0945048 FLANGE NUT M6-1 160-8 P0945160-8 SET SCREW M6-1 X 10
49 P0945049 STUD-DE M6-1 X 100, 12 160-9 P0945160-9 ADJ USTMENT SCREW M4-. 7 X 10
50 P0945050 POWER CORD CLAMP 167 P0945167 POWER CORD 18G 3W 72" 5-15P
51 P0945051 INFEED TABLE SUPPORT 300 P0945300 MOTOR 1-1/2HP 120V 1-PH
54 P0945054 SET SCREW M6-1 X 10 300-1 P0945300-1 CARBON BRUSH
55 P0945055 SUPPORT BRACKET 300-2 P0945300-2 BRUSH HOLDER
56 P0945056 SET SCREW M6-1 X 16 DOG-PT 300-3 P0945300-3 BRUSH COVER
57 P0945057 HEX NUT M6-1 323 P0945323 PADDLE SWITCH ASSEMBLY
58 P0945058 ADJUSTMENT ROD 323-1 P0945323-1 PADDLE SWITCH KEDU HY18 20A
59 P0945059 ADJUSTMENT SHAFT 323-2 P0945323-2 PADDLE SWITCH COVER
Model G0945/G0946/G0947 (Mfd. Since 06/21)
-51-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G0945 Main Parts List
