Grizzly G0945 User Manual

REF PART # DESCRIPTION REF PART # DESCRIPTION
3 P0947003 OUTFEED TABLE SUPPORT 51 P0947051 INFEED TABLE SUPPORT
4 P0947004 SET SCREW M6-1 X 8 54 P0947054 SET SCREW M6-1 X 10
5 P0947005 DUST CHUTE COVER 55 P0947055 SUPPORT BRACKET
6 P0947006 BUTTON HD CAP SCR M6-1 X 12 56 P0947056 SET SCREW M6-1 X 16 DOG-PT
7 P0947007 TAP SCREW 1/4 X 5/8 57 P0947057 HEX NUT M6-1
9 P0947009 FOAM SEAL 58 P0947058 ADJUSTMENT ROD
10 P0947010 DUST CHUTE 59 P0947059 ADJ USTMENT SHAFT
12 P0947012 FRONT BASE PANEL 62 P0947062 RIGHT BASE PANEL
13 P0947013 DUST PORT 4" 64 P0947064 HEX NUT M8-1. 25
14 P0947014 FRONT BEARING RETAINER 70 P0947070 PUSH BLOCK
16 P0947016 BALL BEARING 6201ZZ 71 P0947071 HEX WRENCH 2. 5MM
17 P0947017 EXT RETAINI NG RI NG 12MM 72 P0947072 HEX WRENCH 4MM
20 P0947020 SCALE POINTER 73 P0947073 EXT TOOTH WASHER 5MM
21 P0947021 SCALE GEAR 74 P0947074 HEX NUT M5-. 8
22 P0947022 SCALE PLATE 75 P0947075 LOCK NUT M5-. 8
23 P0947023 KNOB BOLT M8-1.25 X 18, 12-LOBE, D49 100 P0947100 ROUND PLUG 42MM
24 P0947024 FENDER WASHER 8MM 101 P0947101 CUTTERHEAD GUARD
25 P0947025 FOOT PAD 103 P0947103 RUBBER BUMPER
26 P0947026 EXT RETAINI NG RI NG 16MM 104 P0947104 TORSION SPRING 1.6 X 23MM
27 P0947027 PHLP HD SCR M5-.8 X 8 105 P0947105 GUARD MOUNTI NG BRACKET
28 P0947028 BUTTON HD CAP SCR M5-. 8 X 25 106 P0947106 E-CLIP 10MM
29 P0947029 PADDLE SWITCH BOX 125 P0947125 FENCE
34 P0947034 REAR BASE PANEL 128 P0947128 TILT BRACKET
35 P0947035 ROUND PLUG 35MM 129 P0947129 T-SLOT NUT 7, M6-1
36 P0947036 REAR BEARING RETAINER 130 P0947130 SQUARE NUT M8-1.25
38 P0947038 MOTOR PULLEY 131 P0947131 SET SCREW M5-.8 X 8
39 P0947039 CUTTERHEAD PULLEY 132 P0947132 TILT SUPPORT BRACKET
40 P0947040 POLY-V BELT 125J5 133 P0947133 ADJ HANDLE M8-1.25 X 30, 50L
41 P0947041 BELT COVER 135 P0947135 ADJ HANDLE M8-1.25 X 40, 50L
43 P0947043 TABLE ASSEMBLY 136 P0947136 FENCE SLIDE BRACKET
43-1 P0947043-1 TABLE 137 P0947137 FENCE SUPPORT BRACKET
43-2 P0947043-2 SET SCREW M12-1.25 X 15 HOLE-PT, SLOT 138 P0947138 FLAT WASHER 6MM
43-3 P0947043-3 EXTENSION ROD 15 X 326MM 139 P0947139 BUTTON HD CAP SCR M6-1 X 16
43-4 P0947043-4 LEVELING COLLAR 20MM 160 P0947160 CUTTERHEAD ASSEMBLY
43-5 P0947043-5 SET SCREW M8-1.25 X 6 160-1 P0947160-1 SPI RAL CUTTERHEAD 8"
43-6 P0947043-6 HANDLE 25 X 208MM 160-2 P0947160-2 CARBIDE INSERT 14 X 14 X 2
43-7 P0947043-7 BUTTON HD CAP SCR M6-1 X 50 160-3 P0947160-3 FLAT HD TORX T25 M5-.8 X 16
43-8 P0947043-8 FENDER WASHER 6MM 166 P0947166 T-HANDLE TORX DRIVER T-25
43-9 P0947043-9 KNOB BOLT M5-.8 X 10, D16, ROUND KD 167 P0947167 POWER CORD 18G 3W 72" 5-15P
44 P0947044 DUST PORT ADAPTOR 2-1/2" 300 P0947300 MOTOR 1-1/2HP 120V 1-PH
45 P0947045 FOAM SEAL 300-1 P0947300-1 CARBON BRUSH
46 P0947046 CAP SCREW TORX M6-1 X 30 300-2 P0947300-2 BRUSH HOLDER
47 P0947047 FENDER WASHER 6MM 300-3 P0947300-3 BRUSH COVER
48 P0947048 FLANGE NUT M6-1 323 P0947323 PADDLE SWITCH ASSEMBLY
49 P0947049 STUD-DE M6-1 X 150, 12 323-1 P0947323-1 PADDLE SWITCH KEDU HY18 20A
50 P0947050 POWER CORD CLAMP 323-2 P0947323-2 PADDLE SWITCH COVER
Model G0945/G0946/G0947 (Mfd. Since 06/21)
-55-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
G0947 Main Parts List
