Model G0948 (Mfd. Since 08/21)
-57-
Adjusting
Wheel Brush
The lower wheel has a brush (see Figure 76)
that is designed to sweep sawdust off the tire and
blade during operation. In order to work properly,
the brush must make firm contact with the tire.
Tool(s) Needed: Qty
Wrench or Socket 13mm ................................... 1
To adjust wheel brush:
1. DISCONNECT MACHINE FROM POWER!
2.
Open lower wheel cover.
3. On rear of machine, loosen acorn nut
that secures wheel brush in position (see
Figure 76).
4.
Adjust wheel brush so it makes firm, even
contact with wheel without bending the bris-
tles, then tighten acorn nut to secure wheel
brush in place.
Figure 76. Location of wheel brush.
Acorn
Nut
Wheel
Brush
