-84-
Model G4003G (Mfd. Since 1/15)
READ ELECTRICAL SAFETY
ON PAGE 79!
Other Component Wiring Diagrams
Hot
Hot
Ground
G
1
0
220V
NEMA 6-15 Plug
(As Recommended)
LED
Work Light
Spindle Rotation Switch
C
C
NO NO
NC
NC
4
5
1a
1
1b
ON/OFF Switch
KCD1-A
2/8A 250V
Light Socket
7
6
To Electrical
Cabinet
(Page 80)
To Electrical
Cabinet
(Page 80)
To Electrical
Cabinet
(Page 80)
