Grizzly G4003G User Manual

-88-
Model G4003G (Mfd. Since 1/15)
Headstock Gearing Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P4003G0101 EXT RETAINING RING 45MM 138-1 P4003G0138-1 CAMLOCK STUD D1-5
102 P4003G0102 GEAR 36T 139 P4003G0139 KEY 8 X 8 X 80
103 P4003G0103 GEAR 55T 140 P4003G0140 KEY 8 X 8 X 45 W/1 HOLE
104 P4003G0104 KEY 5 X 5 X 18 141 P4003G0141 BUTTON HD CAP SCR M3-.5 X 8
105 P4003G0105 GEAR 35T 142 P4003G0142 SPINDLE D1-5
106 P4003G0106 EXT RETAINING RING 36MM 143 P4003G0143 KEY 8 X 8 X 210
107 P4003G0107 GEAR 45T 144 P4003G0144 CAP SCREW M6-1 X 20
108 P4003G0108 GEAR 58T 145 P4003G0145 INBOUND SPINDLE BEARING COVER
109 P4003G0109 GEAR 21T 146 P4003G0146 INBOARD BEARING COVER GASKET
110 P4003G0110 GEAR 45T 147 P4003G0147 TAPER ROLLER BEARING HR 30212J NSK
111 P4003G0111 EXT RETAINING RING 58MM 148 P4003G0148 HEADSTOCK HOUSING
112 P4003G0112 GEAR 59T 149 P4003G0149 BEARING BLOCK GASKET
113 P4003G0113 GEAR 46T 150 P4003G0150 BEARING BLOCK
114 P4003G0114 CAP SCREW M6-1 X 14 151 P4003G0151 INT RETAINING RING 42MM
115 P4003G0115 GEAR SHAFT COVER (L) 152 P4003G0152 SHAFT
116 P4003G0116 GEAR SHAFT COVER (L) GASKET 153 P4003G0153 OIL SEAL PD25 X 45 X 10
117 P4003G0117 BALL BEARING 6004-2RS 154 P4003G0154 GEAR 40T
118 P4003G0118 SET SCREW M8-1.25 X 6 155 P4003G0155 TAPER ROLLER BEARING HR 30211J NSK
119 P4003G0119 GEAR 83T 156 P4003G0156 SPANNER NUT
120 P4003G0120 O-RING 17 X 2.65 157 P4003G0157 KEY 5 X 5 X 8
121 P4003G0121 GEAR SHAFT 158 P4003G0158 OUTBOARD BEARING COVER GASKET
122 P4003G0122 INT RETAINING RING 47MM 159 P4003G0159 KEY 5 X 5 X 8
123 P4003G0123 COMBO GEAR 40/45T 160 P4003G0160 OUTBOUND SPINDLE BEARING COVER
124 P4003G0124 BALL BEARING 6004-2RS 161 P4003G0161 CAP SCREW M8-1.25 X 12
125 P4003G0125 EXT RETAINING RING 20MM 162 P4003G0162 OIL SEAL PD20 X 45 X 10
126 P4003G0126 BUSHING 163 P4003G0163 SPINDLE PULLEY
127 P4003G0127 SPACER C5 X 20 STEEL 164 P4003G0164 FENDER WASHER 6MM
128 P4003G0128 COMBO GEAR 45/40T 165 P4003G0165 PULLEY SHAFT COVER
129 P4003G0129 FLAT WASHER 6MM 166 P4003G0166 PULLEY SHAFT COVER GASKET
130 P4003G0130 CAP SCREW M6-1 X 16 167 P4003G0167 SPINDLE PULLEY SHAFT SPACER
131 P4003G0131 GEAR SHAFT 168 P4003G0168 KEY 5 X 5 X 30
132 P4003G0132 BALL BEARING 6004-2RS 169 P4003G0169 KEY 5 X 5 X 80
133 P4003G0133 GEAR SHAFT COVER (R) GASKET 170 P4003G0170 SPINDLE PULLEY SHAFT
134 P4003G0134 GEAR SHAFT COVER (R) 171 P4003G0171 GEAR 42T
135 P4003G0135 CAP SCREW M6-1 X 16 DOG-PT 172 P4003G0172 GEAR 23T
136 P4003G0136 COMPRESSION SPRING 173 P4003G0173 GEAR 47T
137V2 P4003G0137V2 SPIDER BOLT SET SCREW M10-1.5 X 30 174 P4003G0174 HEX NUT M10-1.5
