-54-
Model G7947/G7948 (Mfd. Since 01/21)
G7947/48 Labels & Cosmetics
196
ENTANGLEMENT
HAZARD!
Tie back long hair, roll up
long sleeves, and remove
loose clothing, jewelry, or
gloves to prevent getting
caught in moving parts.
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual, call
(800) 523-4777 or go to
www.grizzly.com.
WARNING!
Always wear
ANSI-approved safety
glasses and face
shield when using
this machine.
EYE/FACE INJURY
HAZARD!
WARNING!
WARNING!
NOTICE
Use a light bulb of
60 watts or less!
INJURY/SHOCK
HAZARD!
Disconnect power
before adjustments,
maintenance, or
service.
Always keep this
cover closed
during operation.
PINCH
HAZARD!
WARNING!
WARNING!
191
103V2
193
193
194
195
MODEL G7947 12-SPEED
FLOOR DRILL PRESS
To reduce the risk of serious injury when using this machine:
1. Read and understand owner’s manual before operating.
2. Always wear approved safety glasses.
3. Only plug power cord into a grounded outlet.
4. Disconnect power before setting up or servicing.
5. Avoid entanglement with spindle—tie back long hair, roll up long
sleeves, and DO NOT wear loose clothing, gloves, or jewelry.
6. Properly set up machine before starting.
7. Keep all guards and covers in place during operation.
8. Clamp workpiece to table to prevent rotation.
9. Avoid positioning hands where they could slip into rotating bits.
10. Always remove chuck keys and other tools before starting.
11. Never attempt to slow or stop spindle with hands or tools.
12. Use correct speeds for drilling accessories and workpiece.
13. Do not operate when tired or under influence of drugs or alcohol.
14. Do not expose to rain or use in wet locations.
15. Prevent unauthorized use by children or untrained users;
restrict access or disable machine when unattended.
Motor: 1-1/2 HP, 120V/240V, 1-Ph, 60 Hz
Full Load: 15.8A at 120V, 7.9A at 240V
Spindle to Column Distance: 8-1/2"
Max Spindle to Table Distance: 29"
Spindle to Base Distance: 50-1/4"
Number of Spindle Speeds: 12
Floor to Table Height: 24"–45-1/2"
Spindle Speeds: 180–3240 RPM
Spindle Travel: 4-3/4"
Spindle Taper: MT#3
Weight: 245 lbs.
Date
Mfd. for Grizzly in China
S/N
Specifications
WARNING!
184841
REF PART # DESCRIPTION REF PART # DESCRIPTION
103V2 P7947103V2 MACHINE ID LABEL CSA V2.09.17 (G7947) 194 P7947194 60W LIGHT BULB NOTICE
103V2 P7948103V2 MACHINE ID LABEL CSA V2.09.17 (G7948) 195 P7947195 TOUCH-UP PAINT, GRIZZLY GREEN
191 P7947191 SHOCK-PINCH LABEL 196 P7947196 READ-ENTANGLE-EYE LABEL
193 P7947193 ELECTRICITY WARNING LABEL
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
