H2933/H2934/G0447/G0581 Wide Belt Sander -51-
Wiring Box Components (G0581)
Sanding Motor
Start Delay
Conveyor Motor
Contactor
Emergency Brake
Contactor
UP/DOWN Table Motor
Contactors
Conveyor Motor
Overload Relay
Two 4 Amp Fuses
220V/440V
Three-Phase
Power Supply
Junction Block
Sanding Motor
Contactor
Transformer
Sanding Motor Overload
Relay
Amp Meter Current
Sensor
