Grote 613-VS2-LES - Page 74

1174830.doc
Inverter Parameters
Mitsubishi D-700
Part No. : 1174830
Machine : Auto Load, Inject
Inverter : 1 hp, 230 v, 1121618
Date : 4/15/14
Engineer : JRD
Parameter
No.
Parameter Units Range Res Factory Machine
0 Torque Boost (manual) % 0 to 30 0.1 6 6
1 Upper limit frequency Hz 0 to 120 0.01 120 90 *
2 Lower limit frequency Hz 0 to 60 0.01 0 6*
3 Base frequency Hz 0 to 400 0.01 60 60
4 Multi-speed setting (high speed) Hz 0 to 400 0.01 60 40 *
5 Multi-speed setting (middle speed) Hz 0 to 400 0.01 30 60 *
6 Multi-speed setting (low speed) Hz 0 to 400 0.01 10 40 *
7 Acceleration Time Sec 0 to 3600 0.1 5 0.2 *
8 Deceleration Time Sec 0 to 3600 0.1 5 0.2 *
9 Electronic thermal relay A 0 to 15 0.1 4.1 0.27 *
73 0-5V/0-10V Selection 0 to 1 1 1 1
79 Operation mode 1-4,6,7 1 0 2 *
125 Terminal 2 frequency setting gain
frequency
Hz 0 to 400 0.01 60 60
126 Terminal 4 frequency setting gain
frequency
Hz 0 to 400 0.01 60 60
160 Extended function display selection 0,9999 1 0 0
192 A, B, C, Terminal Function
Selection
0 to 9999 1 99 11 *
C2 Terminal 2 frequency setting bias
frequency
Hz 0 to 400 0.01 0 0
Clr Parameter clear 0, 1, 2 0 0
* denotes machine settings different from factory settings
