TECHNICAL DATA
Motor specifications
Motor model: Battery
Motor type: 20V, 5.0 Ah Lithium-Ion
Drive system
Capacity: Up to 1000/1300 m2
Charging time: 100–120 mins.
Instrument
Working width: 20 cm
Blade system: 3 pcs. blades
Working height min.-max.: 20-60 mm
Height settings: 9
Slope: Max. 24
o
/45%
Dimensions (L x W x H): 55 x 39 x 24 cm
Weight: 7.5 kg
Lift sensor, obstacle sensor, tilt sensor,
slope sensor, rain sensor, multizone.
SAFETY FEATURES
1. Anti-theft device/device-disabling
mechanism
The anti-theft/device-disabling
mechanism prevents others from using
or operating the lawnmower unless
they have a valid code. You will be
asked to enter a four-digit code of your
choosing to use as a security code.
2. Lift sensor
If the lawnmower is lifted more than
10 mm from the ground when in
operation, the blade will stops rotating
immediately.
3. Tilt sensor
If the lawnmower is tilted upwards to
a vertical position, the blade will stop
immediately.
4. Obstacle sensor
The lawnmower detects obstacles in its
way whilst operating. If the lawnmower
encounters an obstacle, it stops driving
in that direction and reverses away
from the obstacle.
5. Rain sensor
The lawnmower has a rain sensor
that can stop the lawnmower in rainy
weather.
6. Emergency stop button
If you press the STOP button,
the lawnmower and blade stop
immediately.
7. Closed battery
The battery that powers the lawnmower
is completely sealed and will not leak
any liquids wherever it is placed.
8. Base station/circuit breaker and
boundary cable
The lawnmower will not work if a
boundary cable is not installed and
activated via the base station. The
lawnmower will not work if the
boundary cable is not connected
correctly or is damaged.
ROBOTIC LAWNMOWER
INTRODUCTION
To get the most out of your new product, please read this instruction manual before
use. Please also keep the instruction manual should you need to refer to it in the future.
