Growatt MOD 11KTL3-X Manual

Index
1 Notes on this manual
2 Safety
3 Product overview
4 Unpacking inspection
5 Installation
6 Inverter wiring
1.1 Validity
1.2 Applicable personnel
1.3 Symbols in this document
2.1 Product description and features
2.2 Qualification of skilled person
2.3 Safety instruction
3.1 Appearance overview
3.2 Dimensions
3.3 Storage environment
5.1 Basic installation requirements
5.2 Mounting wall mount
5.3 Installing the inverter
6.1 Security
6.2 AC side wiring
6.3 DC side wiring
6.4 Connect the signal cable
6.5 Grounding the inverter
6.6 Active power control with smart me-
ter,CT or ripple control signal receiver
6.7 GFCI(Standard)
6.8 Inverter demand response modes
(DRMS)
6.9AFCI(Optional)

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
