6.1 Security
Inverter wiring 6
6.2 AC side wiring
Residual current protection device (RCMU)
Because the inverter itself has a high-precision residual current detection device,it is not recom-
mended to install a leakage protection switch in the system.If for some special reason,it must be
installed between the inverter output and the grid.Please install a type B leakage protection
switch above 300mA. When multiple leakage protection switches are installed in the system,it is
forbidden to share the neutral line,otherwise the leakage protection function may be triggered
by mistake and cause the switch to trip.
16
Danger
Warning
Note
There may be a high voltage in the conductive part of the inverter, which
may cause electric shock.Therefore, when installing the inverter,make
sure that the AC and DC sides of the inverter are powered off.
Static electricity may damage the electronic components of the in-
verter.Anti-static measures should be taken during the replacement or
installation of the inverter.
Moisture and dust penetration can damage the inverter
> Make sure thatthe waterproof cable gland is firmly tightened.
> If the cable connector is not installed correctly, the inverter may be
damaged due to the penetration of moisture and dust. All warranty
claims are void
Danger
Before making electrical connections, please make sure that the DC
switch of the inverter is in the
11
OFF" state and disconnect the AC side
MCB, otherwise the high voltage of the inverter may cause death.
> Each inverter must be installed with an AC circuit breaker inde-
pendently, and it is forbidden to share multiple inverters.
> It is forbidden to use single-core wire at the output terminal of the
inverter.
> It is forbidden to use aluminum wires as output cables.
> Please ensure that the output cable is well connected before turn-
ing on the inverter.lgnoring the above warning may damage the ma-
chine or cause other losses.In this case, the company reserves the right
not to carry out the warranty and bear any responsibility and related
expenses.
Moisture and dust penetration can damage the inverter.
> Make sure the cable connector is securely tightened.
> If the cable connector is not installed correctly, the inverter may be
damaged by moisture and dust. All warranty claims are invalid.
Warning
Note

Other manuals for Growatt MOD 11KTL3-X

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Growatt MOD 11KTL3-X and is the answer not in the manual?

Growatt MOD 11KTL3-X Specifications

General IconGeneral
Product type-
Maximum power11000 W
Output current18.3 A
Output frequency50/60 Hz
MPP voltage range140 - 1000 V
Number of strings per MPPT1
Output power capacity (max)11 kVA
Input operation voltage (max)1100 V
Input operation voltage (min)160 V
Maximum input current per MPPT13 A
Output operation voltage (max)440 V
Output operation voltage (min)340 V
Total Harmonic Distortion (THD)3 %
Number of maximum power point tracking (MPPT)2
Operating temperature (T-T)-25 - 60 °C
Built-in displayYes
Display technologyOLED
Product colorWhite
Overvoltage categoryCAT II
Power protection featuresOver voltage, Short circuit
International Protection (IP) codeIP66
Weight and Dimensions IconWeight and Dimensions
Depth178 mm
Width425 mm
Height387 mm
