Growatt MOD 11KTL3-X Manual

Manufacturer warranty 14
Please refer to the warranty card.
Decommissioning 15
15.1 Dismantling the Inverter
1. Disconnect the inverter as described in section8.
2. Remove all connection cables from the inverter.
15.2 Disposing of the Inverter
Do not dispose of faulty inverters or accessories together with household
waste. Please accordance with the disposal regulations for electronic waste
which apply at the installation site at that time. Ensure that the old unit and,
where applicable, any accessories are disposed of in a proper manner
44
Danger of burn injuries due to hot enclosure parts!
Wait 20 minutes before disassembling until the housing has cooled down.
CAUTION
3. Screw off all projecting cable glands.
4. Lift the inverter off the bracket and unscrew the bracket screws.
15.3 Packing the Inverter
If possible, always pack the inverter in its original carton and secure it with tension belts. If it is
no longer available, you can also use an equivalent carton. The box must be capable of being
closed completely and made to support both the weight and the size of the inverter.
15.4 Storing the Inverter
Store the inverter in a dry place where ambient temperatures are always between -25°C and
+60°C.

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
