Growatt MOD 11KTL3-X Manual

6.8 Inverter demand response modes (DRMS)
This series inverter has the function of demand response modes, We use 16-Pin socket as in-
verter DRMS connection.
6.8.1 16-Pin socket pin assignment
Pin No.
Assignment for inverters capable of both charging and discharging
9
DRM 5
10
DRM 6
11
DRM 7
12
DRM 8
13
RefGen
14
Com/DRMO
15
NC
16
NC
6.8.2 Method of asserting demand response modes
Mode
Socket asserted by
shorting pins
Function
DRM 0
14
13
Operate the disconnection device.
DRM 5
9
13
Do not generate power.
DRM 6
10
13
Do not generate at more than 50% of rated power.
DRM 7
11
13
Do not generate at more than 75% of rated power and re-
duce the reactive power as far as possible.
DRM 8
12
13
Increase power generation (subject to constraints from other
active DRMs).
27
DRMS application description
> Applicable to AS/NZS4777.2:2015 or Commission Regulation (EU)
2016/631.
> DRMO, DRM5, DRM6, DRM7, DRM8 are available.
Damage to the inverter due to moisture and dust penetration
> Make sure the cable gland has been tightened firmly.
> If the cable gland are not mounted properly, the inverter can be de-
stroyed due to moisture and dust penetration. All the warranty claim
will be invalid.
Excessive voltage can damage the inverter! Exter-
nal voltage of DRM PORT don't over +5V.
Information
CAUTION
WAR N ING

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
