Growatt MOD 11KTL3-X Manual

Error code
Description
Suggest
Error 413
IGBT drive fault
1. Restart inverter.
2.If error message still exists,contact manufacturer.
Error 414
EEPROM fault
1. Restart inverter
2.If error message still exists, contact manufacturer.
Error 41 5
In te r na l po wer
test fail(PV Power
low)
1 .Restart inverter.
2.If error message still exists,contact manufacturer.
Error 41 6
O v e r c u r -
r e n t p r o -
t e c t e d b y
software
1. Restart inverter.
2.If error message still exists,contact manufacturer.
Error 41 7
The grid voltage
sampling is incon-
sistent
1 .Restart the machine;
2.If the fault information still exists,contact the manufacturer.
Error 418
DSP and COM firm-
ware version un-
match
1.Check the firmware version.
2.If error message still exists,contact manufacturer.
Error 41 9
Inconsistent leak-
age current sam-
pling
1 .Restart the machine;
2. If the fault information still exists,contact the manufac-
turer.
Error 420
G FC I M o d u l e
damage
1: After shutdown,Check the leakage current module 2: If the
error message still exists, contact manufacturer
Error 421
CPLD is abnormal
1. Restart inverter.
2.If error message still exists,contact manufacturer.
Error 422
s a m p l i n g i s
inconsistent
1. Restart inverter.
2.If error message still exists,contact manufacturer.
Error 425
AFCI self-test fault
1 .Restart inverter
2.If error message still exists, contact manufacturer.
43

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
