Growatt MOD 11KTL3-X Manual

Warning
message
Description
Suggest
Warning 207
U d is k over-current
protection
1 .Unplug the U disk
2.Re-access U disk after shutdown
3.If the error message still exists, contact
manufacturer.
Warning 208
DC Fuse Open
1 .After shutdown,Check fuse.
2. If e r r o r m e s s a g e s ti l l e x i s t s , con ta ct
manufacturer.
Warning 209
The DC input voltage is
e x c e e d i n g t h e
m ax im u m to le rab le
value.
1 .Immediately disconnect the DC switch and check
the voltage
2.If the fault code still exists after the normal voltage
is restored, contact manufacturer.
Warning 210
PV Reversed
1 .Check PV input terminals
2. If e r r o r m e s s a g e s ti l l e x i s t s , c o n t a ct
manufacturer.
Warning 300
No Utility
1 .Please confirm grid is lost or not.
2. If e r r o r m e s s a g e s ti l l e x i s t s , con ta ct
manufacturer.
Warning 301
Grid voltage outrange
1 .Check the AC voltage is in the range of standard
voltage in specification.
2. If e r r o r m e s s a g e s ti l l e x i s t s , c o n t a ct
manufacturer.
Warning 302
Grid frequency outrange
1 .Check the frequency is in the range of specification
or not.
2. If e r r o r m e s s a g e s ti l l e x i s t s , co n t a ct
manufacturer.
Warning 303
EPS mode, over load
1 .Please reduce the load of EPS output.
2. If e r r o r m e s s a g e s ti l l e x i s t s , con ta ct
manufacturer.
Warning 304
CT Open or Wrong
1 .Check if AC current sensor is connected well 2 . I f
e rro r me s sa g e s t i l l exi st s, c o n t a ct manu-
facturer.
Warning 305
CT line reversed or
Ground fail
1.Check the L line and N line of SP-CT is reversed or
not.
2. If e r r o r m e s s a g e s ti l l e x i s t s , c o n t a ct
manufacturer.
Warning 306
Communication fault M3
didn't receive SP-CT
data
1 .Check communication wire
2. If e r r o r m e s s a g e s ti l l e x i s t s , con ta ct
manufacturer.
Warning 307
Communication fault
1 .Check communication wire.
2. If e r r o r m e s s a g e s ti l l e x i s t s , c o n t a ct
manufacturer.
Warning 400
Fan function abnormal
1 .After shutdown,Check the fan connection.
2. replace the fan.
3.If the error message still exists, contact manufac-
turer.
39

Growatt MOD 11KTL3-X Specifications

General

Product type	-
Maximum power	11000 W
Output current	18.3 A
Output frequency	50/60 Hz
MPP voltage range	140 - 1000 V
Number of strings per MPPT	1
Output power capacity (max)	11 kVA
Input operation voltage (max)	1100 V
Input operation voltage (min)	160 V
Maximum input current per MPPT	13 A
Output operation voltage (max)	440 V
Output operation voltage (min)	340 V
Total Harmonic Distortion (THD)	3 %
Number of maximum power point tracking (MPPT)	2
Operating temperature (T-T)	-25 - 60 °C
Built-in display	Yes
Display technology	OLED
Product color	White
Overvoltage category	CAT II
Power protection features	Over voltage, Short circuit
International Protection (IP) code	IP66

Weight and Dimensions

Depth	178 mm
Width	425 mm
Height	387 mm
