How to set the server address and domain name
(1) Login to the built-in page with the login account as "admin" and password as
"admin", select "Server" in the left list of "System Settings", and select "Enable";
Figure 3- 27 Schematic diagram of server settings
(2) Enter the port number of the corresponding server, the domain name of the server,
such as server-cn.growatt.com/server.growatt.com , and the time interval for data
uploading, click Submit, and it will prompt to refresh the interface successfully to check
whether the modification is successful.
Figure 3- 28 Prompt for successful server setup
(3) After the setting is successful, it needs to be restarted to take effect.
1. If the interface is not refreshed for a long time after clicking Save when adding a
device, power off and restart the collector. After restarting, click "Device Status" to
check whether the last operation was successful.
2. When configuring the parameters of the corresponding functions, only the
parameters of the corresponding function should be configured as described above,
other parameters not related to the desired configuration function remain unchanged.
ShineSEM-X (without electricity meter)
Rated input voltage/range (three
specifications)
Rated input frequency/range
Maximum number of inverter
connections
Maximum communication
distance
RS485 standard twisted pair shielded cable: 1000m
Ethernet cable: 100m
Dimensions
(height*width*thickness)
Range of working temperature
Specification parameters and model description 4
4.1 Specification parameters
