Growatt ShineSEM-X User Manual

Product introduction and installation 2
Figure 2-1 Appearance (unit: mm)
Serial number
Label
Illustrate
1
L1/L2/L3/PE
Three-phase voltage interface
2
L/N
Single-phase voltage interface
3
COM1
RS485-1 interface
4
CT
Current transformer interface
5
COM2
RS485-2 interface
6
COM4
RS485-4 interface
7
COM3
RS485-3 interface
8
COM5
CAN bus interface
9
LAN/ANT
Network cable/antenna interface
10
FXL
Fiber optic interface
11
DI/DO
Digital signal input and output interface
12
AI/AO
Analog signal input and output interface
1 About this manual
1.1 Manual description
1.4 Manual usage
Please read this manual carefully before installing and using the smart array
communication box. Also, keep this manual in a safe place where it can be easily found
by operating and maintenance personnel. The contents of this manual are subject to
constant updating and correction and there will inevitably be minor discrepancies or
errors with the actual product. Users are advised to refer to the actual product
purchased, and can download the latest user manual through oss.growatt.com, or
obtain the latest user manual through Growatt's sales or service channels.
1.2 Copyright notice
1.3 Applicable personnel
Dear user, thank you for using the ShineSEM-X developed and produced by Shenzhen
Growatt New Energy Co., Ltd. (hereinafter referred to as Growatt). Performance and
functionality make more comments. The purpose of this manual is to provide users with
detailed product information and instructions for installation, operation and
maintenance.
The copyright of this user manual is owned by Growatt. No part or all of this user manual
may be excerpted, reproduced or transmitted in any form, including information and
publications, by any entity or individual without our written permission. Infringement of
which will be prosecuted.
The version number of this manual is V1.0. Growatt has the final right to interpret this
user manual. In case of changes in product parameters, appearance, packaging, etc.,
the latest information of the company shall prevail without prior notice.
This manual is intended for technical professionals who install, commission and maintain
the ShineSEM-X and for users who carry out routine operations. If necessary, please refer
to the appropriate user information from Growatt.
2.1 Product appearance and internal structure

Growatt ShineSEM-X Specifications

General

Brand	Growatt
Model	ShineSEM-X
Category	Inverter
Language	English
