Growatt SPH Series Operation Manual

41
42
Chart 6.7
Chart 6.8
1.Under the Basic Para, you can see the setup options below after pressing Enter for 1S：
In the basic Parameter, you can set language (English, Italian, German), system time,
Lead-acid CV(default is 550V), Lead-acid LV(default is 160V)Lead-acid CC(default is
20A).
2.Under the Back Up, you can see the setup options below after pressing Enter for 1S:
In the back up you can set EPS, including enable or disable (default is enable), AC
voltage(default is 230V) and frequency (default site 50HZ).
3.Under the Priority, you can see the setup options below after pressing Enter:
Chart 6.9
Chart 6.10
Note:
Ø“Power Rate” is used to set up power of battery. So different battery may have the
different power, customer need to check the max power of battery.
ØTime setting is 24-hour.If the end time is less than beginning time, it defaults to
spanning days.
4.Under the Mode Change, you can see the setup options below after pressing Enter:
The Mode change has two options what are sensor and battery type，sensor is
meter(default) .In the battery type, you can choose lithium battery or lead-acid battery.
WorkMode
BackUp
WorkMode
WorkMode
WorkMode
Backup: Enable
ACVolt: 230 V
WorkMode
AC Freq: 50 Hz
Press “enter” key more
than 1 seconds to make sure
Press “down”
key to the next item
Press “enter” key more
than 1 seconds to make sure
EPS setup
240
208
60
Disable
Mode Change
WorkMode
Battery Type
WorkMode
Lithium
WorkMode
Lead-acid
Press “enter” key to
make sure
Press “down”
key to the next item
Press “enter” key to
make sure
WorkMode
Stop SOC: 100%
Stop SOC: 5%
WorkMode
Time
WorkMode
Power Rate: 100 %
Power Rate: 100 %
Priority
WorkMode
WorkMode
Opt: Load First
WorkMode
WorkMode
WorkMode
AC CHG: Enable
WorkMode
SC : _ _ _ _
WorkMode
00:00 – 00:00
WorkMode
Save ：OK
WorkMode
Time
WorkMode
00:00 – 00:00
WorkMode
Save ：OK
If battery first is choosen
WorkMode
Bat First: OK
If you need to enable AC charging
function, you need key password
Range from 5% to 100%,
and the accuracy is 1%
Range from 5% to 100%,
and the accuracy is 1%
If Grid first is choosen
Range from 5% to 100%,
and the accuracy is 1%
Range from 5% to 100%,
and the accuracy is 1%
Press “down”
key to the next item
Press “down”
key to the next item
Choose “OK” to
the next item
Choose “OK” to
the next item
Bat First
Grid First
NO Disable
NO
NO
WorkMode
Grid First: OK
NO
WorkMode WorkMode
Language
WorkMode
English
Italian
German
WorkMode
Lead-acid LV
WorkMode
160V
WorkMode
Lead-acid CC
WorkMode
20 A
WorkMode
System time
Press “enter” key more
than 1 seconds to make sure
Press “down”
key to the next item
Press “enter” key more
than 1 seconds to make sure
Range from 160 to 550V,
and the accuracy is 1V
Range from 0 to 21A, and
the accuracy is 1A
WorkMode
Lead-acid CV
Range from 160 to 550V,
and the accuracy is 1V
Basic Parameter
Only display when
battery type is lead-acid
WorkMode
550V
WorkMode
xxD/xxM/xxxxY XX:XX
WorkMode WorkMode
Language
WorkMode
English
Italian
German
WorkMode
Lead-acid LV
WorkMode
160V
WorkMode
Lead-acid CC
WorkMode
21 A
WorkMode
System time
Press “enter” key more
than 1 seconds to make sure
Press “down”
key to the next item
Press “enter” key more
than 1 seconds to make sure
Range from 160 to 550V,
and the accuracy is 1V
WorkMode
Lead-acid CV
Range from 160 to 550V,
and the accuracy is 1V
Basic Parameter
Only display when
battery type is lead-acid
WorkMode
550V
WorkMode
xxD/xxM/xxxxY XX:XX
