7 8
3 Product Description
3.1 Growatt SPH series inverter
Marks of SPH
3.2 Label Explanation
Label contains the following information: for example SPH6000 shows as below:
Mark
Description
Explanation
Push-button
Status symbol of
SPH
Operation of display screen and set system
Green light on
SPH run normally
Red light on
fault state
Red light
blinking
1.Alarm state
2.Software updating

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Growatt SPH3000 and is the answer not in the manual?

Growatt SPH3000 Specifications

General IconGeneral
ModelSPH3000
CategoryInverter
Rated Power3000 W
Max. DC Voltage550 V
MPPT Voltage Range120 V - 500 V
AC Output Voltage230 V
Frequency50/60Hz
Dimensions505 x 453 x 198 mm
Weight26 kg
Start Voltage150 V
Nominal DC Voltage360 V
Number of MPP Trackers2
AC Nominal Power3000 W
Max. AC Apparent Power3000VA
AC Voltage Range180-280V
Power Factor0.8 leading to 0.8 lagging
THDi<3%
AC Connection TypeSingle Phase
Max. Charging Current50A
Max. Discharging Current50A
Max. DC Power for Charging/Discharging3000W
Protection DegreeIP65
Cooling MethodNatural Convection
Max. Output Power3000 W
Max. Efficiency97.5%
THD<3%
Battery Voltage Range40-60V
CommunicationWiFi
Operating Temperature Range-25 ~ +60 °C
