Growatt SPH3000 User Manual

42-59Vdc
the type of product
PV input data
Max input power
PV input range
Number of input strings
Max input current per string
AC output data
Max AC apparent power
Max AC output current
AC nominal voltage
Power factor
Stand alone
Rated AC output power
Rated output voltage
Battery data
Battery voltage range
Max charge and discharge current of
battery
Environment
Operating temperature range
Degree of protection
Certificates and approvals
Growatt SPH6000
4000W/4000W
120-550Vdc
2/1
12A
6000VA
27A
230V,50/60Hz
0.8 leading~0.8 lagging
3000W
230V,50/60Hz
66A
Lead battery and lithium battery
-25℃~+60℃
IP 65
G83,G59,AS4777,CEI
0-21,CE,IEC62109,AS/NZS
3100,VDE
0126-1-1,VDE-AR-N4105
type of battery
10
Description of label:
3.3 Size and weight
3.4 The advantage of the unit of Growatt SPH
Features below:
·All in one design. Can improve self consumption, back up and also pinch the valley.
·Smart management,work mode can be set.
·Safe battery used.
·Easy installation.
·Max efficiency 97.5%.
·Two mpp tracker input.
Growatt SPH
A(mm)
weight（kg）
450 565 180
B(mm)
C(mm)
27
9
Chart 3.1

Growatt SPH3000 Specifications

General

Model	SPH3000
Category	Inverter
Rated Power	3000 W
Max. DC Voltage	550 V
MPPT Voltage Range	120 V - 500 V
AC Output Voltage	230 V
Frequency	50/60Hz
Dimensions	505 x 453 x 198 mm
Weight	26 kg
Start Voltage	150 V
Nominal DC Voltage	360 V
Number of MPP Trackers	2
AC Nominal Power	3000 W
Max. AC Apparent Power	3000VA
AC Voltage Range	180-280V
Power Factor	0.8 leading to 0.8 lagging
THDi	<3%
AC Connection Type	Single Phase
Max. Charging Current	50A
Max. Discharging Current	50A
Max. DC Power for Charging/Discharging	3000W
Protection Degree	IP65
Cooling Method	Natural Convection
Max. Output Power	3000 W
Max. Efficiency	97.5%
THD	<3%
Battery Voltage Range	40-60V
Communication	WiFi
Operating Temperature Range	-25 ~ +60 °C
