The A line's concluding information as follow:
1.Standby state: SPH is in standby state. No error in this state, but for other reasons, make it in a
wait state.
2.Normal state: SPH is normal working state.
3.Checking state: SPH is in self-check state, if there is no error or warning, SPH will go to normal
state or standby state. Otherwise it will go to fault state.
4.Programming state: SPH is in updating firmware state.
5.Fault state : SPH has fault information, it will be in stopped operational protection state.
The B line's information as follow:
In normal, it will turn on page automatically, when pushing the button “down”, the
order of the paging information as follow:
Chart 6.5
Note:
1.“down” control command (if pushing “up” button, command will go back)
2.Workmode depend on the situation. If SPH is normal state, it will show
”normal”. If SPH is standby state, it will show as “standby” etc.
3.Some special definitions are explained, for example: Vb means the voltage of
battery. Cb means the capacity of lithium battery (only lithium battery show this
data). Pm means the monitor power of user.
6.4.4 work mode set up
keep pressing “enter ”for 3S,you can enter set up surface,in the set up surface you
need hold button Enter or ESC 1S for selection,you can see the surface as showing
below.
Basic Para
WorkMode
WorkMode
Configuration
WorkMode
MODE Change
WorkMode
Default Set
WorkMode
Priority
WorkMode
BackUp
Press “enter” key more than
3 seconds into setup mode
Press “down” key
to the next item
Press “enter” key more
than 1 seconds to make sure
Chart 6.6
1.under the Basic Para ,you can see the setup options below after pressing Enter for
1S：
Chart 6.7
WorkMode WorkMode
Language
WorkMode
English
Italian
German
WorkMode
System time
WorkMode
xxD/xxM/xxxxY
WorkMode
Lead-acid CV
WorkMode
58.0 V
WorkMode
Lead-acid CC
WorkMode
60 A
Press “enter” key more
than 1 seconds to make sure
Press “down” key
to the next item
Press “enter” key more
than 1 seconds to make sure
Range from 55 to 60V,
and the accuracy is 0.1V
Range from 0 to 60A, and
the accuracy is 0.1A
WorkMode
Lead-acid LV
WorkMode
48V
Range from 42 to 50V,
and the accuracy is 0.1V
Basic Parameter
Only display when
battery type is lead-acid
Only display when
battery type is lead-acid
Only display when
battery type is lead-acid
WorkMode
Input&Output Para
WorkMode
(Lead acid)Vb:xx.xV
(Lithium)Vb/Cb:xx.xV/xxx%
WorkMode
Vpv:xxxV/xxxV
WorkMode
Ppv:xxxxW/xxxxW
PV1/PV2 voltage
Battery
information
WorkMode
Grid:xxxV/xxHz
WorkMode
EPS:xxxV/xxHz
WorkMode
Po:xxxxW/xxxxVA
Grid information
Output AC Power
EPS output voltage
WorkMode
EPS:xxxxW/xxxxVA
WorkMode
Pbat: (+/-)XXXX W
Battery power
EPS output power
WorkMode
Epv_d:xxxx.x KWh
WorkMode
Epv_a:xxxx.x KWh
WorkMode
Ec_d:xxxx.x KWh
WorkMode
Ec_a:xxxx.x KWh
WorkMode
Ed_d:xxxx.x KWh
WorkMode
Ed_a:xxxx.x KWh
WorkMode
SerNo:xxxxxxxxxx
PV1/PV2 today energy
PV1/PV2 total energy
PV1/PV2 input power
Battery Charge_today
energy
WorkMode
Pm: (+/-)XXXXW
WorkMode
Per_Load: %
EPS load ratio
Power to grid or to user
Battery Charge_total
energy
Battery Discharge_today
energy
Battery Discharge_total
energy
WorkMode
20XX/XX/XX/ XX:XX
System Time
WorkMode
Model:xxxxxxxxxx
WorkMode
FW Version:xxxx
Serial number
Machine model
Firmware version
To grid is +
To user is -
WorkMode
Eac_d:xxxx.x KWh
WorkMode
Eac_a:xxxx.x KWh
AC output_Etoday
AC output_Etotal
