6.2 Control parameters, output assembly 1
The control parameters are output parameters for controlling the digital dosing pump. All the settings and control actions represented by
the EtherNet/IP control parameters below can also be done from the operating panel, unless otherwise stated.
The present status of each parameter can be read from the associated Dynamic status parameter. See section 6.6 Dynamic status
parameters, input assembly 2.
Note that to enable any control from bus, the bus
control must be activated in the Setup menu via the
operating panel of the DDA pump.
Parameters
Name Data type Scaling
Range/
Resolution
Description
1 SetRemoteLocal
SINT8, 0xC2 Bool (state) 0, 1
Setting of Remote/Local state.
0: Local (outputs disabled)
1: Remote
2SetStartStop
Setting of pump Start/Stop state.
0: Stop pump
1: Start pump
3SetStopKeyOn
Setting of the operating panel Stop key On/
Off.
0: Local start
1: Local stop
4 SetDeaeratingOnOff
Setting of Deaerating On/Off state.
0: Deaerating off
1: Deaerating on
5 SetAnalogMode
Setting of Analog Mode:
0: 0-20 mA
1: 4-20 mA (default)
6 SetTimerMode
Setting of Timer Mode (Opr. mode Timer).
0: Cycle timer
1: Week timer
7 SetSlowModeVelocity
Setting of Slow Mode velocity.
0: 50 % (default)
1: 25 %
8 SetSlowModeEnable
Enabling of Slow Mode (Anti-cavitation).
0: Disable
1: Enable
9 SetAutoDeaeratingEnable
Enabling of the Auto-deaerating function.
0: Disable
1: Enable
10 SetFlowControlEnable
SINT8, 0xC2 Bool (state) 0, 1
Enabling of the Flow Control function.
0: Disable
1: Enable
11 SetWatchdogEnable
Enabling of the fieldbus watchdog. Done
automatically when bus control is selected
from the operating panel.
0: Disable
1: Enable
12 SetAutoFlowAdaptEnable
Enabling of the Auto Flow Adapt function.
0: Disable
1: Enable
13 SetPulseMemoryEnable
Enabling of the Pulse Memory function.
0: Disable
1: Enable
14 SetOutputRelay1
Control of output relay 1. Not possible from
the operating panel.
0: Inactive
1: Active
15 SetOutputRelay2
Control of output relay 2. Not possible from
the operating panel.
0: Inactive
1: Active
