6. Detailed description of data parameters
6.1 Connection and assembly overview
TM07 5213 3419
Dosing
pump
Connection 1: Pump control and status
Overall input, assembly 1
• Dynamic status, assembly 2
• Static status, assembly 3
• System measurements, assembly 4
Explicit messages only, SetPressureMax
Connection 2: Pump status
Overall input, assembly 1
Connection 3: Dynamic status
Dynamic status, assembly 2
Connection 4: Static status
Static status, assembly 3
Connection 5: Measurements
System measurements, assembly 4
Control, assembly 11
Controller
