6.7 Static status parameters, input assembly 3
Static status parameters are parameters that describe characteristics of the digital dosing pump. They are constants whose values cannot
change.
This assembly is included in assembly 1.
6.7.1 Device identification
The UnitFamily and the UnitType parameters identify what dosing product EtherNet/IP is connected to.
6.8 Measured parameters, input assembly 4
Measured parameters are physical values measured by internal and external sensors and values calculated by the digital dosing pump
itself based on measured values and its state/mode behaviour.
This assembly is included in assembly 1.
Parameters
Name Data type Scaling
Range/
Resolution
Description
200 UnitFamily
SINT8, 0xC2
Enum
0-127
Unit Family
201 UnitType Unit Type
202 UnitVersion Unit Version
203 CIMSoftwareVersion
1
CIM Software Version
204 CIMSoftwareRevision CIM Software Revision
205 CIMSoftwareFix CIM Software Fix
206 StatusReserved1 Reserved for future use
207 StatusReserved2 Reserved for future use
UnitFamily [enumeration] UnitType [enumeration]
30: Smart Digital Dosing, DDA
1: Smart Digital Dosing, DDA
2: Smart Digital Dosing, DDC
2: Smart Digital Dosing, DDA XL
Parameters
Name Data type Scaling
Range/
Resolution
Description
300 ActualSetpointManual
SINT32, 0xC4
0.1 ml/h
0 - Max. for
pump type
Actual value of Setpoint used in operating
mode “Manual”. Can be set via
SetpointManual (parameter 30) or at the
operating panel.
301 ActualPulseVolume 1 nl
Actual value of Pulse Volume used in
operating mode “Pulse”. Can be set via
SetPulseVolume (parameter 31) or at the
operating panel.
302 ActualBatchDosingVolume 0.001 ml
Actual value of Batch Dosing Volume used in
operating mode “Batch”. Can be set via
SetBatchDosingVolume (parameter 32) or at
the operating panel.
303 ActualBatchDosingTime 0.1 s
Actual value of Batch Dosing Time used in
operating mode “Batch”. Can be set via
SetBatchDosingTime (parameter 33) or at the
operating panel.
304 ActualPressureMax
SINT16, 0xC3 0.1 bar
0 - Max. for
pump type
Actual value of max. pressure alarm limit
setting. Can be set via SetPressureMax
(parameter 50) or at the operating panel.
305 DosingPressureMax
Dosing pressure max., fixed for this pump
type from factory.
306 DosingCapacityMax
SINT32, 0xC4
0.1 ml/h
0 - Max. for
pump type
Dosing capacity max., fixed for this pump
type from factory.
307 DosingCapacityReference 0.1 ml/h
Dosing capacity setpoint shown in the
display. Represents the actual setpoint
belonging to the actual operating mode and
dosing state.
308 MeasuredDosingCapacity 0.1 ml/h
Measured actual dosing capacity. The
SetFlowControlEnable bit (parameter 10)
must be set for this value to be available.
