10. StopFromExternal
DWORD,
0xD3
Bool (state) 0, 1
Status of Stop from external digital input DI3.
0: Stop signal from external digital input DI3 is not
active.
1: Stop signal from external digital input DI3 is
active.
11. StopFromBus
Status of Stop from bus.
0: Stop command from bus is not active.
1: Stopped from bus with SetStartStop command
(parameter 2).
12. AutoDeaeratingED
Status of Auto Deaerating E/D.
0: Auto Deaerating disabled.
1: Auto Deaerating enabled. The digital output,
DO5, goes high if Auto Deaerating becomes active.
13. FlowControlED
Status of Flow Control E/D.
0: Flow Control function disabled.
1: Flow Control function enabled.
14. WatchdogED
Status of EtherNet/IP Watchdog E/D.
0: EtherNet/IP watchdog disabled.
1: EtherNet/IP watchdog enabled. The watchdog is
automatically enabled/disabled when “Bus control”
is selected/deselected on the operating panel. The
software watchdog can be enabled/disabled
independently via SetWatchdogEnable (parameter
11).
15. AutoFlowAdaptED
Status of Auto Flow Adapt E/D.
0: Auto Flow Adapt function disabled. (Default if
Flow Control function is disabled).
1: Auto Flow Adapt function enabled.
16. PulseMemoryED
Status of Pulse Memory E/D.
0: Pulse Memory function disabled.
1: Pulse Memory function enabled.
17. BusControlLocallyED
Status of Bus Control Locally E/D. This indicates
whether “Bus control” has been enabled in the
Settings menu on the operating panel.
0: Bus control not enabled from the operating
panel. The setting of the SetRemoteLocal control
bit has no effect.
1: Bus control enabled from the operating panel.
The setting of the SetRemoteLocal control bit
transfers control of all settings to the bus.
18. ResetAlarmAck
Status of TrigResetAlarm command.
0: TrigResetAlarm ready to execute.
1: TrigResetAlarm execution acknowledge. The bit
is cleared when TrigResetAlarm is set to 0.
19. PulseAck
Status of TrigPulse command.
0: TrigPulse ready to execute.
1: TrigPulse execution acknowledge. The bit is
cleared when TrigPulse is set to 0.
20. ResetVolumeCntAck
Status of TrigResetVolumeCnt command.
0: TrigResetVolumeCnt ready to execute.
1: TrigResetVolumeCnt execution acknowledge.
The bit is cleared when TrigResetVolume is set to
0.
21. SetRTCAck
Status of TrigSetRTC command.
0: TrigSetRTC ready to execute.
1: TrigSetRTC execution acknowledge. The bit is
cleared when TrigResetAlarm is set to 0.
101
Digital Outputs
BYTE, 0xD1
Array of Bools Digital outputs
0. DO1
Bool (state) 0, 1
Status of DO1 – Relay 1
1. DO2 Status of DO2 – Relay 2
2. DO3 Status of DO3
3. DO4 Status of DO4
4. DO5 Status of DO5 – Auto Deaerating
Parameter
Name Data type Scaling
Range/
Resolution
Description
