8.9 "Signal relays" 1 and 2 ("Relay outputs")
Pump variant
"Signal relays" 1 and 2
("Relay outputs")
CME
CRE, CRIE, CRNE, CRKE,
SPKE, MTRE
The pump incorporates two signal relays for potential-free
signalling. For further information, see the section on megging.
Function
You can configure the signal relays to be activated by one of the
following incidents:
"Not active".
"Ready".
The pump can be running or is ready to run and no alarms are
present.
"Alarm".
There is an active alarm and the pump is stopped.
"Operating" ("Operation").
"Operating" equals "Running" but the pump is still in operation
when the pump is stopped due to low flow. See the section on
low-flow detection.
"Running" ("Pump running").
The pump is running.
"Warning".
There is an active warning.
"Limit 1 exceeded"
When this function is activated, the signal relay is activated. See
the section on the limit-exceeded function.
"Limit 2 exceeded".
When this function is activated, the signal relay is activated. See
the section on the limit-exceeded function.
"External fan control" ("Control of external fan").
When you select "External fan control", the relay is activated if
the internal temperature of the motor electronics reach a preset
limit value.
Factory setting
See the section on factory settings.
Related information
8.15 "Limit-exceeded function"
8.17 "Stop function" ("Low-flow stop function")
9.2 Factory settings
11.2 Megging
8.10 "Analog output"
Pump variant "Analog output"
CME
CRE, CRIE, CRNE, CRKE, SPKE, MTRE
Whether the analog output is available or not, depends on the
functional module fitted in the pump:
Function (terminal)
FM 200
1)
(standard)
FM 300
1)
(advanced)
"Analog output" -
1)
See the section on the identification of functional module.
The analog output enables the reading of certain operating data to
external control systems.
To set the analog output, make the settings below.
"Output signal"
"0-10 V"
"0-20 mA"
"4-20 mA".
"Function of analog output"
"Actual speed"
Signal range
[V, mA]
"Actual speed"
[%]
0 100 200
"0-10 V" 0 V 5 V 10 V
"0-20 mA" 0 mA 10 mA 20 mA
"4-20 mA" 4 mA 12 mA 20 mA
The reading is a percentage of the rated speed.
"Actual value"
Signal range
[V, mA]
"Actual value"
Sensor
min
Sensor
max
"0-10 V" 0 V 10 V
"0-20 mA" 0 mA 20 mA
"4-20 mA" 4 mA 20 mA
The reading is a percentage of the range between the minimum and
maximum value.
"Resulting setpoint"
Signal range
[V, mA]
"Resulting setpoint"
[%]
0 100
"0-10 V" 0 V 10 V
"0-20 mA" 0 mA 20 mA
"4-20 mA" 4 mA 20 mA
The reading is a percentage of the external setpoint range.
42
