17.7 Inputs and outputs
17.7.1 Mains supply (L1, L2, L3)
17.7.2 Motor output (U, V, W)
1)
Output voltage in % of supply voltage.
2)
Depending on the pump family selected.
17.7.3 RS-485 GENIbus connection
The RS-485 circuit is functionally separated from other central
circuits and galvanically separated from the supply voltage
(PELV).
17.7.4 Digital inputs
All digital inputs are galvanically separated from the supply
voltage (PELV) and other high-voltage terminals.
17.7.5 Signal relays
1)
IEC 60947, parts 4 and 5.
The relay contacts are galvanically separated from other circuits
by reinforced insulation (PELV).
17.7.6 Analog inputs
1)
The factory setting is voltage signal "U".
All analog inputs are galvanically separated from the supply
voltage (PELV) and other high-voltage terminals.
17.7.7 Analog output
The analog output is galvanically separated from the supply
voltage (PELV) and other high-voltage terminals.
17.7.8 MCB 114 sensor input module
17.8 Sound pressure level
The sound pressure of the CUE is maximum 70 dB(A).
The sound pressure level of a motor controlled by a frequency
converter may be higher than that of a corresponding motor
which is not controlled by a frequency converter. See section
7.7 RFI filters.
18. Disposal
This product or parts of it must be disposed of in an
environmentally sound way:
1. Use the public or private waste collection service.
2. If this is not possible, contact the nearest Grundfos company
or service workshop.
Subject to alterations.
Supply voltage 200-240 V ± 10 %
Supply voltage 380-500 V ± 10 %
Supply voltage 525-600 V ± 10 %
Supply voltage 525-690 V ± 10 %
Supply frequency 50/60 Hz
Maximum temporary imbalance between
phases
3 % of rated value
Leakage current to ground > 3.5 mA
Number of cut-ins, enclosure A Max. 2 times/min.
Number of cut-ins, enclosures B and C Max. 1 time/min.
Do not use the power supply for switching the
CUE on and off.
Output voltage 0-100 %
1)
Output frequency 0-100 Hz
2)
Switching on output Not recommended
Terminal number 68 (A), 69 (B), 61 GND (Y)
Terminal number 18, 19, 32, 33
Voltage level 0-24 VDC
Voltage level, open contact > 19 VDC
Voltage level, closed contact < 14 VDC
Maximum voltage on input 28 VDC
Input resistance, R
i
Approx. 4 kΩ
Relay 01, terminal number 1 (C), 2 (NO), 3 (NC)
Relay 02, terminal number 4 (C), 5 (NO), 6 (NC)
Maximum terminal load (AC-1)
1)
240 VAC, 2 A
Maximum terminal load (AC-15)
1)
240 VAC, 0.2 A
Maximum terminal load (DC-1)
1)
50 VDC, 1 A
Minimum terminal load
24 V DC 10 mA
24 V AC 20 mA
C Common
NO Normally open
NC Normally closed
Analog input 1, terminal number 53
Voltage signal A53 = "U"
1)
Voltage range 0-10 V
Input resistance, R
i
Approx. 10 kΩ
Maximum voltage ± 20 V
Current signal A53 = "I"
1)
Current range 0-20, 4-20 mA
Input resistance, R
i
Approx. 200 Ω
Maximum current 30 mA
Maximum fault, terminals 53, 54 0.5 % of full scale
Analog input 2, terminal number 54
Current signal A54 = "I"
1)
Current range 0-20, 4-20 mA
Input resistance, R
i
Approx. 200 Ω
Maximum current 30 mA
Maximum fault, terminals 53, 54 0.5 % of full scale
Analog output 1, terminal number 42
Current range 0-20 mA
Maximum load to frame 500 Ω
Maximum fault 0.8 % of full scale
Analog input 3, terminal number 2
Current range 0/4-20 mA
Input resistance < 200 Ω
Analog inputs 4 and 5, terminal number 4, 5 and 7, 8
Signal type, 2- or 3-wire Pt100/Pt1000
When using Pt100 with 3-wire cable, the
resistance must not exceed 30
Ω
.
